Datasheet

R1304BTLSFAN R1304BTSSFAN
Order Code
R1304BTLSFAN
R1304BTLSFANNA
R1304BTSSFAN
R1304BTSSFANNA
Form Factor
1U Rack 1U Rack
Server Board
S120 0B TL S120 0B TS
Drive Bays
Four fixed 2.5” or 3.5’’ SATA HDDs
Optional slim-line optical drive
Four fixed 2.5” or 3.5’’ SATA HDDs
Optional slim-line optical drive
System Cooling
3 x 40mm fixed fans with duct 3 x 40mm fixed fans with duct
Power Supply
250-watt non-redundant power supply 250-watt non-redundant power supply
Add-in Card Support
One full height PCI Express* 2.0 x8 through riser card
in slot 6
One full height PCI Express* 2.0 x8 through riser card
in slot 4
I/O Expansion Module Support
Optional SAS Module NA
Dimensions (H x W x D)
17.24” x 1.75” x 21.8” (438mm x 45mm x 553mm) 17.24” x 1.75” x 21.8” (438mm x 45mm x 553mm)
Components Included
*Heat sinks not included
l
Intel® Server Board S1200BTL
l
Intel® Server Chassis R1304
l
250-watt non-redundant power supply
l
One low profile PCI Express* riser card
l
Slim-line CD-ROM bay
l
Pre-routed cables
l
Intel® Server Board S1200BTS
l
Intel® Server Chassis R1304
l
250-watt non-redundant power supply
l
One low profile PCI Express* riser card
l
Slim-line CD-ROM bay
l
Pre-routed cables
Management Hardware
Integrated IPMI 2.0 baseboard management controller
Optional:
Intel® Remote Management Module 4 or Intel® RMM 4 Lite
Intel® Trusted Platform Module
Fan Speed Control via Super I/O chip
Management Software
Intel® Deployment Assistant
Intel® System Management Software
Intel® Deployment Assistant
Intel® Server System R1304BTLSFAN/ R1304BTSSFAN Technical Specifications
1U servers that are the lowest priced rack systems ever offered by Intel
• Optional SAS or Remote Management module for R1304BTL model only
• Supports up to 4 xed HDDs
