BIOS Settings Glossary version 19

BIOS Settings Glossary BACK
V19 – November 2012 BACK
Overridden
Processor Speed
Main
Information
only
Displays the maximum processor speed at current
settings. Defined as current host clock frequency x
maximum non-turbo ratio.
This BIOS setting is present only on Intel® Desktop
Boards where the Host Clock Frequency or Maximum
Non-Turbo Ratio have been overridden.
Overridden
Processor Turbo
Speed
Main
Information
only
Displays the maximum processor speed at current
settings. Defined as current host clock frequency x 1-
core active turbo ratio.
This BIOS setting is present only on Intel® Desktop
Boards where the Host Clock Frequency or Turbo Ratios
have been overridden.
P
BIOS Setting
Appears on BIOS Screen…
Options
Description / Purpose
Panel Power Cycle
Delay Time (ms)
Configuration > Video >
Advanced Flat Panel Display
Settings
Numeric
Specifies the delay for panel power cycling.
Panel Power-Down
Delay Time (ms)
Configuration > Video >
Advanced Flat Panel Display
Settings
Numeric
Specifies the delay for panel power-down.
Panel Power-On
Delay Time (ms)
Configuration > Video >
Advanced Flat Panel Display
Settings
Numeric
Specifies the delay from system power-on to panel
power-on.
Parallel Port
Configuration >On-Board
Devices
• Enable
• Disable
Enables or disables the parallel port.
Partial Intel® AMT
Reset
Intel® ME > Intel® Active (or
Standard) Management
Technology Configuration
Continue?
(Y/N)
Resets all Intel
®
AMT configuration settings to their
factory defaults except Intel
®
ME password, PSKs
(PID/PPS), domain name, and host name.
Partial Intel®
Standard
Manageability
Reset
Intel® ME > Intel® Standard
Management Technology
Configuration
Continue?
(Y/N)
Resets all Intel
®
Standard Manageability configuration
settings to their factory defaults except Intel
®
ME
password, PSKs (PID/PPS), domain name, and host
name.
Pass Thru DMA
Security > Intel® VT for
Directed I/O (VT-d)
• Enable
• Disable
Enables or disables Isoch/Non-Isoch VT-d Engine Pass-
Thru DMA Support
PAVP
Configuration > Video
• Lite
• Disable
Protected Audio-Video Path (PAVP) protects content
when using hardware-accelerated audio/video decoding.
It requires a processor/chipset that supports PAVP. This
BIOS setup item is not displayed in BIOS Setup and is
only accessible via the Intel® Integrator Toolkit (ITK).
PCH Core
Performance
Information
only
Displays the default, proposed and active PCH core
voltage.
PCH Core Voltage
Override
Performance > Bus Overrides
Multiple voltage
values
PCH Core Voltage might need to be adjusted when
raising Uncore/QPI Voltage under the configuration page
to achieve stable operation.
PCI Bus Frequency
Performance > Bus Overrides
Information
only
Displays the PCI bus frequency
PCI Bus Limit
Configuration > On-Board
Devices
• 64
• 128
• 256
Configures PCI Bus Limit to 64, 128, or 256. This will
reserve 64, 128, or 256 MB of memory address space
below 4 GB.
