Serial Number
Main > System Identification
Information > Chassis
Information
Information
only
Displays the chassis manufacturer serial number string
from SMBIOS Type 3 structure.
Serial Number
Main > System Identification
Information > Desktop Board
Information
Information
only
Displays the board serial number string from SMBIOS
Type 2 structure.
Serial Number
Main > System Identification
Information > System
Information
Information
only
Displays the system serial number string from SMBIOS
Type 1 structure.
Serial Port x
Configuration > On-Board
Devices
• Enable
• Disable
Enables or disables the serial port(s).
Serial Port Swap
Configuration > On-Board
Devices
• Enable
• Disable
If enabled, swaps Serial Port numbering so that Ports 1
and 2 are mapped to the back panel and Ports 3 and 4
are mapped to onboard headers.
Server FQDN
Intel® ME > Intel® Active (or
Standard) Management
Technology Configuration >
View Provisioning Record
Information
only
Displays the provisioning server FQDN.
Server IP Address
Intel® ME > Intel® Active (or
Standard) Management
Technology Configuration >
View Provisioning Record
Information
only
Displays the provisioning server IP address.
Set Master Key
Hard Disk Drive
Password
Security
User defined
Sets the Master Key Hard Disk Drive password
The Master Key HDD password is only used to unlock a
drive if the HDD password is forgotten. It does not lock a
drive by itself. HDD Passwords are not recoverable and
cannot be removed without the original password. The
drive will remain inaccessible unless the HDD or Master
Key HDD password is entered.
Set Hard Disk Drive
Password
Security
User defined
Sets the Hard Disk Drive password
If a HDD Password is created, it must be entered each
boot before operating system access. HDD Passwords
are not recoverable and cannot be removed without the
original password. The drive will remain inaccessible
unless the HDD or Master Key HDD password is entered.
Set PRTC
Intel® ME > Intel® Active (or
Standard) Management
Technology Configuration
User defined
Sets the Intel® AMT PRTC (Protected Real Time Clock).
Enter PRTC in Greenwich Mean Time (GMT) format:
YYYY:MM:DD:HH:MM:SS
Set Supervisor
Password
Security
User defined
Sets the Supervisor password.
The supervisor password gives unrestricted access to
view and change all Setup options. If only the supervisor
password is set, pressing <Enter> at the password
prompt of Setup gives the user restricted access to
Setup. If both the supervisor and user passwords are set,
you must enter either the supervisor password or the
user password to access Setup. Setup options are then
available for viewing and changing depending on whether
the supervisor or user password was entered.
