BIOS Settings Glossary version 19

BIOS Settings Glossary BACK
V19 – November 2012 BACK
Display F9 for
Remote
Assistance
Boot > Boot Display Options
• Enable
• Disable
If set to Enable, BIOS will display “F9 for Remote Assistance”
prompt. F9 key input will still be accepted if this prompt is
disabled.
This BIOS setting is present only when the board supports
Remote Assistance.
Display F10 to
Enter Boot Menu
Boot > Boot Display Options
• Enable
• Disable
If enabled, BIOS will display “F10 to Enter Boot Menu”
prompt. F10 key input will still be accepted if this prompt is
disabled.
Display F12 for
Network Boot
Boot > Boot Display Options
• Enable
• Disable
If enabled, BIOS will display “F12 for Network Boot” prompt.
F12 key input will still be accepted if this prompt is disabled.
Domain Name
Intel® ME > Intel® Active (or
Standard) Management
Technology Configuration >
Local Setup and
Configuration
User defined
Sets the domain name (name of the network the computer is
connected to).
Duty Cycle
Increment
Configuration > Fan Control
& Real-Time Monitoring
Numeric
Fan Control will increase fan duty by this % for each degree
over Minimum Temperature.
Dynamic DNS
Update
Intel® ME > Intel® Active (or
Standard) Management
Technology Configuration >
Local Setup and
Configuration
• Enable
• Disable
Enable: Intel® ME attempts to register its IP address and
FQDN in DNS (Domain Name System) using the Dynamic
DNS Update protocol.
Disable: Intel® ME will make no attempt to update DNS.
IPv6 requires dedicated FQDN for DDNS (Dynamic DNS).
Dynamic DNS TTL
Intel® ME > Intel® Active (or
Standard) Management
Technology Configuration >
Local Setup and
Configuration
Numeric
When Dynamic DNS Update is enabled, this sets the DDNS
(Dynamic DNS) Time-To-Live value. If set to zero, the value
will be the internal default of 15 minutes or 1/3 DHCP lease
time.
E
BIOS Setting
Appears on BIOS Screen…
Options
Description / Purpose
ECC Event Logging
Performance > Memory
Overrides
• Enable
• Disable
Enables or disables event logging of ECC events.
EDID Data Source
Configuration > Video >
Advanced Flat Panel Display
Settings
• Flat Panel
Display
• Custom
Payload
• Pre-Defined
Flat panel display parameters will be read from the
selected source.
eDP Data Rate
Configuration > Video >
Advanced Flat Panel Display
Settings
• 1.62 Gbps
• 2.70 Gbps
Sets the data rate for the Embedded DisplayPort (eDP)
link. This will be used if the sink indicates that no aux
handshake is required during link training.
eDP Interface Type
Configuration > Video >
Advanced Flat Panel Display
Settings
• Single-Lane
• Dual-Lane
• Quad-Lane
Sets the Embedded DisplayPort (eDP) connectivity.
Enable IPv6
Intel® ME > Intel® Active (or
Standard) Management
Technology Configuration >
Local Setup and Configuration
> IPv6 TCP/IP Configuration
• Enable
• Disable
Enable: Intel® ME IPv6 addresses are dedicated and not
shared with the Host Operating System.
Disable: Intel ® ME IPv6 addresses are shared with the
host operating system.
