Vol. 3 22-1
CHAPTER 22
VM ENTRIES
Software can enter VMX non-root operation using either of the VM-entry instructions
VMLAUNCH and VMRESUME. VMLAUNCH can be used only with a VMCS whose launch
state is clear and VMRESUME can be used only with a VMCS whose the launch state
is launched. VMLAUNCH should be used for the first VM entry after VMCLEAR; VMRE-
SUME should be used for subsequent VM entries with the same VMCS.
Each VM entry performs the following steps in the order indicated:
1. Basic checks are performed to ensure that VM entry can commence
(Section 22.1).
2. The control and host-state areas of the VMCS are checked to ensure that they are
proper for supporting VMX non-root operation and that the VMCS is correctly
configured to support the next VM exit (Section 22.2).
3. The following may be performed in parallel or in any order (Section 22.3):
• The guest-state area of the VMCS is checked to ensure that, after the
VM entry completes, the state of the logical processor is consistent with
IA-32 and Intel 64 architectures.
• Processor state is loaded from the guest-state area and based on controls in
the VMCS.
• Address-range monitoring is cleared.
4. MSRs are loaded from the VM-entry MSR-load area (Section 22.4).
5. If VMLAUNCH is being executed, the launch state of the VMCS is set to
“launched.”
6. An event may be injected in the guest context (Section 22.5).
Steps 1–4 above perform checks that may cause VM entry to fail. Such failures occur
in one of the following three ways:
• Some of the checks in Section 22.1 may generate ordinary faults (for example,
an invalid-opcode exception). Such faults are delivered normally.
• Some of the checks in Section 22.1 and all the checks in Section 22.2 cause
control to pass to the instruction following the VM-entry instruction. The failure is
indicated by setting RFLAGS.ZF
1
(if there is a current VMCS) or RFLAGS.CF (if
there is no current VMCS). If there is a current VMCS, an error number indicating
the cause of the failure is stored in the VM-instruction error field. See Chapter 5
1. This chapter uses the notation RAX, RIP, RSP, RFLAGS, etc. for processor registers because most
processors that support VMX operation also support Intel 64 architecture. For IA-32 processors,
this notation refers to the 32-bit forms of those registers (EAX, EIP, ESP, EFLAGS, etc.). In a few
places, notation such as EAX is used to refer specifically to lower 32 bits of the indicated register.
