Intel 64 and IA-32 Architectures Software Developers Manual Volume 3B, System Programming Guide Part 2

Vol. 3 23-31
VM EXITS
• IA32_DEBUGCTL.BTF = 0 and the cause of a pending debug
exception was the execution of a single instruction.
• IA32_DEBUGCTL.BTF = 1 and the cause of a pending debug
exception was a taken branch.
— Suppose that a VM exit is due to another reason (but not a debug exception)
and occurs while there is MOV-SS blocking of debug exceptions. In this case,
the value saved sets bits corresponding to the causes of any debug
exceptions that were pending at the time of the VM exit. If the VM exit occurs
immediately after VM entry (no instructions were executed in VMX non-root
operation), the value saved may match that which was loaded on VM entry
(see Section 22.6.3). Otherwise, the following items apply:
• Bit 12 (enabled breakpoint) is set to 1 if there was at least one matched
data or I/O breakpoint that was enabled in DR7. Bit 12 is also set if it had
been set on VM entry, causing there to be valid pending debug exceptions
(see Section 22.6.3) and the VM exit occurred before those exceptions
were either delivered or lost. In other cases, bit 12 is cleared to 0.
• The setting of bit 14 (BS) is implementation-specific. However, it is not
set if RFLAGS.TF = 0 or IA32_DEBUGCTL.BTF = 1.
— The reserved bits in the field are cleared.
• If the “save VMX-preemption timer value” VM-exit control is 1, the value of timer
is saved into the VMX-preemption timer-value field. This is the value loaded from
this field on VM entry as subsequently decremented (see Section 21.7.1). (If the
“save VMX-preemption timer value” VM-exit control is 0, VM exit does not modify
the value of the VMX-preemption timer-value field.)
• If the logical processor supports the 1-setting of the “enable EPT” VM-execution
control, values are saved into the four (4) PDPTE fields as follows:
— If the “enable EPT” VM-execution control is 1 and the logical processor was
using PAE paging at the time of the VM exit, the PDPTE values currently in use
are saved:
1
• The values saved into bits 11:9 of each of the fields is undefined.
• If the value saved into one of the fields has bit 0 (present) clear, the value
saved into bits 63:1 of that field is undefined. That value need not
correspond to the value that was loaded by VM entry or to any value that
might have been loaded in VMX non-root operation.
• If the value saved into one of the fields has bit 0 (present) set, the value
saved into bits 63:12 of the field is a guest-physical address.
1. A logical processor uses PAE paging if CR0.PG = 1, CR4.PAE = 1 and IA32_EFER.LMA = 0. See
Section 3.8 in the Intel® 64 and IA-32 Architectures Software Developer’s Manual, Volume 3A.
Note that “enable EPT” is a secondary processor-based VM-execution control. If bit 31 of the pri-
mary processor-based VM-execution controls is 0, VM exit functions as if the “enable EPT” VM-
execution control were 0. See Section 20.6.2.
