VIRTUAL-MACHINE MONITOR PROGRAMMING CONSIDERATIONS
is 1, the logical processor supports the capability MSRs
IA32_VMX_TRUE_PINBASED_CTLS, IA32_VMX_TRUE_PROCBASED_CTLS,
IA32_VMX_TRUE_EXIT_CTLS, and IA32_VMX_TRUE_ENTRY_CTLS. These capability
MSRs report, respectively, on the allowed settings of all of the pin-based VM-execu-
tion controls, the primary processor-based VM-execution controls, the VM-exit
controls, and the VM-entry controls.
Software may use one of the following high-level algorithms to determine the correct
default control settings:
1
1. The following algorithm does not use the details given in Appendix G.2:
a. Ignore bit 55 of the IA32_VMX_BASIC MSR.
b. Using RDMSR, read the VMX capability MSRs IA32_VMX_PINBASED_CTLS,
IA32_VMX_PROCBASED_CTLS, IA32_VMX_EXIT_CTLS, and
IA32_VMX_ENTRY_CTLS.
c. Set the VMX controls as follows:
i) If the relevant VMX capability MSR reports that a control has a single
setting, use that setting.
ii) If (1) the relevant VMX capability MSR reports that a control can be set to
0 or 1; and (2) the control’s meaning is known to the VMM; then set the
control based on functionality desired.
iii) If (1) the relevant VMX capability MSR reports that a control can be set to
0 or 1; and (2) the control’s meaning is not known to the VMM; then set
the control to 0.
A VMM using this algorithm will set to 1 all controls in the default1 class (in
step (c)(i)). It will operate correctly even on processors that allow some
controls in the default1 class to be 0. However, such a VMM will not be able to
use the new features enabled by the 0-setting of such controls. For that reason,
this algorithm is not recommended.
2. The following algorithm uses the details given in Appendix G.2. This algorithm
requires software to know the identity of the controls in the default1 class:
a. Using RDMSR, read the IA32_VMX_BASIC MSR.
b. Use bit 55 of that MSR as follows:
i) If bit 55 is 0, use RDMSR to read the VMX capability MSRs
IA32_VMX_PINBASED_CTLS, IA32_VMX_PROCBASED_CTLS,
IA32_VMX_EXIT_CTLS, and IA32_VMX_ENTRY_CTLS.
ii) If bit 55 is 1, use RDMSR to read the VMX capability MSRs
IA32_VMX_TRUE_PINBASED_CTLS,
1. These algorithms apply only to the pin-based VM-execution controls, the primary processor-
based VM-execution controls, the VM-exit controls, and the VM-entry controls. Because there are
no secondary processor-based VM-execution controls in the default1 class, a VMM can always
set to 0 any such control whose meaning is unknown to it.
