DEBUGGING AND PERFORMANCE MONITORING
• Debug store (DS) feature flag (bit 21), returned by the CPUID
instruction — Indicates that the processor provides the debug store (DS)
mechanism, which allows BTMs to be stored in a memory-resident BTS buffer.
See Section 18.7.8, “Branch Trace Store (BTS).”
• Last Branch Record (LBR) Stack — The LBR stack consists of 8 MSRs
(MSR_LASTBRANCH_0 through MSR_LASTBRANCH_7); bits 31-0 hold the ‘from’
address, bits 63-32 hold the ‘to’ address (MSR addresses start at 40H). See
Figure 18-9.
• Last Branch Record Top-of-Stack (TOS) Pointer — The TOS Pointer MSR
contains a 3-bit pointer (bits 2-0) to the MSR in the LBR stack that contains the
most recent branch, interrupt, or exception recorded. For Intel Core Solo and
Intel Core Duo processors, this MSR is located at register address 01C9H.
For compatibility, the Intel Core Solo and Intel Core Duo processors provide two 32-
bit MSRs (the MSR_LER_TO_LIP and the MSR_LER_FROM_LIP MSRs) that duplicate
functions of the LastExceptionToIP and LastExceptionFromIP MSRs found in P6 family
processors.
For details, see Section 18.7, “Last Branch, Interrupt, and Exception Recording
(Processors based on Intel NetBurst
®
Microarchitecture),” and Appendix B.6, “MSRs
In Intel® Core™ Solo and Intel® Core™ Duo Processors.”
Figure 18-8. IA32_DEBUGCTL MSR for Intel Core Solo
and Intel Core
Duo Processors
31
TR — Trace messages enable
BTINT — Branch trace interrupt
BTF — Single-step on branches
LBR — Last branch/interrupt/exception
Reserved
87654321 0
BTS — Branch trace store
Reserved
