A-54 Vol. 3
PERFORMANCE-MONITORING EVENTS
62H 02H UNC_DRAM_PAGE_M
ISS.CH1
Counts the number of precharges
(PRE) that were issued to DRAM
channel 1 because there was a
page miss. A page miss refers to a
situation in which a page is
currently open and another page
from the same bank needs to be
opened. The new page experiences
a page miss. Closing of the old page
is done by issuing a precharge.
62H 04H UNC_DRAM_PAGE_M
ISS.CH2
Counts the number of precharges
(PRE) that were issued to DRAM
channel 2 because there was a
page miss. A page miss refers to a
situation in which a page is
currently open and another page
from the same bank needs to be
opened. The new page experiences
a page miss. Closing of the old page
is done by issuing a precharge.
63H 01H UNC_DRAM_READ_C
AS.CH0
Counts the number of times a read
CAS command was issued on DRAM
channel 0.
63H 02H UNC_DRAM_READ_C
AS.AUTOPRE_CH0
Counts the number of times a read
CAS command was issued on DRAM
channel 0 where the command
issued used the auto-precharge
(auto page close) mode.
63H 04H UNC_DRAM_READ_C
AS.CH1
Counts the number of times a read
CAS command was issued on DRAM
channel 1.
63H 08H UNC_DRAM_READ_C
AS.AUTOPRE_CH1
Counts the number of times a read
CAS command was issued on DRAM
channel 1 where the command
issued used the auto-precharge
(auto page close) mode.
63H 10H UNC_DRAM_READ_C
AS.CH2
Counts the number of times a read
CAS command was issued on DRAM
channel 2.
Table A-3. Non-Architectural Performance Events In the Processor Uncore for Intel
Core i7 Processors
Event
Num.
Umask
Value
Event Mask
Mnemonic Description Comment
