A-162 Vol. 3
PERFORMANCE-MONITORING EVENTS
3: RETURN
4: INDIRECT
Return branches.
Returns, indirect calls, or indirect
jumps.
CCCR Select 02H CCCR[15:13]
Event Specific
Notes
This event may overcount
conditional branches if:
• Mispredictions cause the trace
cache and delivery engine to
build new traces.
• When the processor's pipeline
is being cleared.
retired_branch
_type
This event counts retiring
branches by type. Specify one or
more mask bits to qualify the
branch by its type
ESCR restrictions MSR_TBPU_ESCR0
MSR_TBPU_ESCR1
Counter numbers
per ESCR
ESCR0: 4, 5
ESCR1: 6, 7
ESCR Event Select 04H ESCR[30:25]
ESCR Event Mask
Bit
1: CONDITIONAL
2: CALL
ESCR[24:9]
Conditional jumps.
Direct or indirect calls.
3: RETURN
4: INDIRECT
Return branches.
Returns, indirect calls, or indirect
jumps.
CCCR Select 02H CCCR[15:13]
Event Specific
Notes
This event may overcount
conditional branches if :
• Mispredictions cause the trace
cache and delivery engine to
build new traces.
• When the processor's pipeline
is being cleared.
Table A-9. Performance Monitoring Events Supported by Intel NetBurst
Microarchitecture for Non-Retirement Counting (Contd.)
Event Name Event Parameters Parameter Value Description
