B-106 Vol. 3
MODEL-SPECIFIC REGISTERS (MSRS)
When this bit is clear (0, default),
the processor does not change the
VID signals or the bus to core ratio
when the processor enters a
thermal managed state.
If the TM2 feature flag (ECX[8]) is
not set to 1 after executing CPUID
with EAX = 1, then this feature is
not supported and BIOS must not
alter the contents of this bit
location. The processor is
operating out of spec if both this
bit and the TM1 bit are set to
disabled states.
17:14 Reserved.
18 3, 4, 6 ENABLE MONITOR FSM. (R/W)
see Table B-2
19 Adjacent Cache Line Prefetch
Disable. (R/W)
When set to 1, the processor
fetches the cache line of the 128-
byte sector containing currently
required data. When set to 0, the
processor fetches both cache lines
in the sector.
Single processor platforms should
not set this bit. Server platforms
should set or clear this bit based
on platform performance
observed in validation and testing.
BIOS may contain a setup option
that controls the setting of this bit.
21:20 Reserved.
22 3, 4, 6 Limit CPUID MAXVAL. (R/W)
see Table B-2
Table B-6. MSRs in the Pentium 4 and Intel Xeon Processors (Contd.)
Register
Address
Register Name
Fields and Flags
Model
Avail-
ability
Shared/
Unique
1
Bit Description
Hex Dec
