Vol. 3 B-115
MODEL-SPECIFIC REGISTERS (MSRS)
369H 873 MSR_FLAME_CCCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.3, “CCCR MSRs.”
36AH 874 MSR_FLAME_CCCR2 0, 1, 2,
3, 4, 6
Shared See Section 18.18.3, “CCCR MSRs.”
36BH 875 MSR_FLAME_CCCR3 0, 1, 2,
3, 4, 6
Shared See Section 18.18.3, “CCCR MSRs.”
36CH 876 MSR_IQ_CCCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.3, “CCCR MSRs.”
36DH 877 MSR_IQ_CCCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.3, “CCCR MSRs.”
36EH 878 MSR_IQ_CCCR2 0, 1, 2,
3, 4, 6
Shared See Section 18.18.3, “CCCR MSRs.”
36FH 879 MSR_IQ_CCCR3 0, 1, 2,
3, 4, 6
Shared See Section 18.18.3, “CCCR MSRs.”
370H 880 MSR_IQ_CCCR4 0, 1, 2,
3, 4, 6
Shared See Section 18.18.3, “CCCR MSRs.”
371H 881 MSR_IQ_CCCR5 0, 1, 2,
3, 4, 6
Shared See Section 18.18.3, “CCCR MSRs.”
3A0H 928 MSR_BSU_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3A1H 929 MSR_BSU_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3A2H 930 MSR_FSB_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3A3H 931 MSR_FSB_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3A4H 932 MSR_FIRM_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3A5H 933 MSR_FIRM_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3A6H 934 MSR_FLAME_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3A7H 935 MSR_FLAME_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
Table B-6. MSRs in the Pentium 4 and Intel Xeon Processors (Contd.)
Register
Address
Register Name
Fields and Flags
Model
Avail-
ability
Shared/
Unique
1
Bit Description
Hex Dec
