B-116 Vol. 3
MODEL-SPECIFIC REGISTERS (MSRS)
3A8H 936 MSR_DAC_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3A9H 937 MSR_DAC_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3AAH 938 MSR_MOB_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3ABH 939 MSR_MOB_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3ACH 940 MSR_PMH_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3ADH 941 MSR_PMH_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3AEH 942 MSR_SAAT_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3AFH 943 MSR_SAAT_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3B0H 944 MSR_U2L_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3B1H 945 MSR_U2L_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3B2H 946 MSR_BPU_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3B3H 947 MSR_BPU_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3B4H 948 MSR_IS_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3B5H 949 MSR_IS_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3B6H 950 MSR_ITLB_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3B7H 951 MSR_ITLB_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3B8H 952 MSR_CRU_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
Table B-6. MSRs in the Pentium 4 and Intel Xeon Processors (Contd.)
Register
Address
Register Name
Fields and Flags
Model
Avail-
ability
Shared/
Unique
1
Bit Description
Hex Dec
