Vol. 3 B-117
MODEL-SPECIFIC REGISTERS (MSRS)
3B9H 953 MSR_CRU_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3BAH 954 MSR_IQ_ESCR0 0, 1, 2 Shared See Section 18.18.1, “ESCR MSRs.”
This MSR is not available on later
processors. It is only available on
processor family 0FH, models
01H-02H.
3BBH 955 MSR_IQ_ESCR1 0, 1, 2 Shared See Section 18.18.1, “ESCR MSRs.”
This MSR is not available on later
processors. It is only available on
processor family 0FH, models
01H-02H.
3BCH 956 MSR_RAT_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3BDH 957 MSR_RAT_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3BEH 958 MSR_SSU_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3C0H 960 MSR_MS_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3C1H 961 MSR_MS_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3C2H 962 MSR_TBPU_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3C3H 963 MSR_TBPU_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3C4H 964 MSR_TC_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3C5H 965 MSR_TC_ESCR1 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3C8H 968 MSR_IX_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
3C9H 969 MSR_IX_ESCR0 0, 1, 2,
3, 4, 6
Shared See Section 18.18.1, “ESCR MSRs.”
Table B-6. MSRs in the Pentium 4 and Intel Xeon Processors (Contd.)
Register
Address
Register Name
Fields and Flags
Model
Avail-
ability
Shared/
Unique
1
Bit Description
Hex Dec
