DEBUGGING AND PERFORMANCE MONITORING
MSR_UNCORE_PERF_GLOBAL_STATUS provides overflow status of the U-clock
performance counters in the uncore. This is a read-only register. If an overflow status
bit is set the corresponding counter has overflowed. The register provides a condition
change bit (bit 63) which can be quickly checked by software to determine if a signif-
icant change has occurred since the last time the condition change status was
cleared. Figure 18-30 shows the layout of MSR_UNCORE_PERF_GLOBAL_STATUS.
• OVF_PCn (bit n, n = 0, 7): When set, indicates general-purpose uncore counter
MSR_UNCORE_PerfCntr n has overflowed.
• OVF_FC0 (bit 32): When set, indicates the fixed-function uncore counter
MSR_UNCORE_FixedCntr0 has overflowed.
• OVF_PMI (bit 61): When set indicates that an uncore counter overflowed and
generated an interrupt request.
• CHG (bit 63): When set indicates that at least one status bit in
MSR_UNCORE_PERF_GLOBAL_STATUS register has changed state.
MSR_UNCORE_PERF_GLOBAL_OVF_CTRL allows software to clear the status bits in
the UNCORE_PERF_GLOBAL_STATUS register. This is a write-only register, and indi-
vidual status bits in the global status register are cleared by writing a binary one to
the corresponding bit in this register. Writing zero to any bit position in this register
has no effect on the uncore PMU hardware.
Figure 18-29. Layout of MSR_UNCORE_PERF_GLOBAL_CTRL MSR
PMI_FRZ (R/W)
EN_PMI_CORE3 (R/W)
EN_PMI_CORE2 (R/W)
EN_PMI_CORE1 (R/W)
87 0
EN_PMI_CORE0 (R/W)
32
3
48
1
Reserved
63
2
4
31
56
62 495051
EN_PC7 (R/W)
EN_PC6 (R/W)
EN_PC5 (R/W)
EN_PC4 (R/W)
EN_PC3 (R/W)
EN_PC2 (R/W)
EN_PC1 (R/W)
EN_PC0 (R/W)
EN_FC0 (R/W)
RESET Value — 0x00000000_00000000
