General Information

Intel

Pentium

4 Processor on 90 nm Process Specification Update 21

General Information

Figure 1. Intel

Pentium

4 Processor on 90 nm Process in the 478-pin Package

2-D Matrix Mark

m c

`03

SSPEC/Country

of Assy

FPO

Product Code

AAAAAAAA

NNNN

ATPO

Serial #

INTEL

PENTIUM® 4

X.XXGHZ / 1M / 800

SLXXX MALAY

BBBBBBBB

Brand

Figure 2. Intel

Pentium

4 Processors 570, 560, 550, 540, 530 and 520

Supporting Hyper-

Threading Technology on 90 nm Process in the 775-Land LGA Package

LOT

S/N

INTEL m ‘04

Pentium 4

3.60GHZ/1M/800

SLxxx [COO]

[FPO]

Brand

SSPEC /Country of Assy

2-D Matrix Mark

Frequency/Cache/

Bus

Figure 3. Intel

Pentium

4 Processors 571, 561, 551, 541, 531 and 521

Supporting Hyper-

Threading Technology on 90 nm Process in the 775-Land LGA Package
