Intel Pentium 4 Processor on 90 nm Process

Identification Information
R
Intel
®
Pentium
®
4 Processor on 90 nm Process Specification Update 23
Identification Information
The Pentium 4 processor on 90 nm process can be identified by the following values:
Family
1
Model
2
1111b 0011b
1111b 0100b
NOTES:
1. The Family corresponds to bits [11:8] of the EDX register after RESET, bits [11:8] of the EAX register after
the CPUID instruction is executed with a 1 in the EAX register, and the generation field of the Device ID
register accessible through Boundary Scan.
2. The Model corresponds to bits [7:4] of the EDX register after RESET, bits [7:4] of the EAX register after
the CPUID instruction is executed with a 1 in the EAX register, and the model field of the Device ID
register accessible through Boundary Scan.
Table 1. Intel
®
Pentium
®
4 Processor on 90 nm Process Processor Identification
Information
S-Spec
Core
Stepping
L2 Cache
Size (bytes) CPUID Speed Core/Bus Package and Revision Notes
SL7D7 C0 512K 0F33h 2.26GHz/533MHz
35.0 x 35.0 mm
FC-mPGA4 Rev 2.0
1, 4, 7, 19
SL7FY C0 1M 0F33h 2.40GHz/800MHz
35.0 x 35.0 mm
FC-mPGA4 Rev 2.0
2, 4, 7, 11
SL7E8 C0 1M 0F33h 2.40GHz/533MHz
35.0 x 35.0 mm
FC-mPGA4 Rev 2.0
2, 4, 7
SL7E9 C0 1M 0F33h 2.66GHz/533MHz
35.0 x 35.0 mm
FC-mPGA4 Rev 2.0
1, 4, 7, 19
SL7D8 C0 1M 0F33h 2.80GHz/533MHz
35.0 x 35.0 mm
FC-mPGA4 Rev 2.0
2, 4, 7
SL79K C0 1M 0F33h 2.80GHz/800MHz
35.0 x 35.0 mm
FC-mPGA4 Rev 2.0
2, 4, 7, 11
SL79L C0 1M 0F33h 3.00GHz/800MHz
35.0 x 35.0 mm
FC-mPGA4 Rev 2.0
2, 4, 7, 11
SL79M C0 1M 0F33h 3.20GHz/800MHz
35.0 x 35.0 mm
FC-mPGA4 Rev 2.0
1, 4, 6, 11
SL7B8 C0 1M 0F33h 3.20GHz/800MHz
35.0 x 35.0 mm
FC-mPGA4 Rev 2.0
2, 4, 6, 11
SL7B9 C0 1M 0F33h 3.40GHz/800MHz
35.0 x 35.0 mm
FC-mPGA4 Rev 2.0
4, 6, 11
SL7AJ C0 1M 0F33h 3.40GHz//800MHz
35.0 x 35.0 mm
FC-mPGA4 Rev 2.0
1, 4, 6, 11
