Identification Information

R

Intel

®

Pentium

®

4 Processor on 90 nm Process Specification Update 27

Table 1. Intel

®

Pentium

®

4 Processor on 90 nm Process Processor Identification

Information

S-Spec

Core

Stepping

L2 Cache

Size (bytes) CPUID Speed Core/Bus Package and Revision Notes

SL84X E0 1M 0F41h 3.60GHz/800MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

1, 4, 9, 11, 13, 14, 15

SL7Q2 E0 1M 0F41h 3.60GHz/800MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

2, 4, 9, 11, 13, 14, 15

SL7NZ E0 1M 0F41h 3.60GHz/800MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

2, 4, 9, 11, 12, 13, 14, 15

SL8J6 E0 1M 0F41h 3.60GHz/800MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

2, 4, 9, 11, 12, 13, 14, 15

SL82U E0 1M 0F41h 3.80GHz/800MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

2, 4, 9, 11, 13, 14, 15

SL84Y E0 1M 0F41h 3.80GHz/800MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

1, 4, 9, 11, 13, 14, 15

SL7P2 E0 1M 0F41h 3.80GHz/800MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

2, 4, 9, 11, 12, 13, 14, 15

SL8J7 E0 1M 0F41h 3.80GHz/800MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

2, 4, 9, 11, 12, 13, 14, 15

SL8K4 G1 1M 0F49h 3.40GHz/800Mhz

35.0 x 35.0 mm

FC-mPGA4 Rev 2.0

2, 4, 7, 11

SL8K2 G1 1M 0F49h 3.20GHz/800Mhz

35.0 x 35.0 mm

FC-mPGA4 Rev 2.0

2, 4, 7, 11

SL8JZ G1 1M 0F49h 3.00GHz/800Mhz

35.0 x 35.0 mm

FC-mPGA4 Rev 2.0

2, 4, 7, 11

SL8PL G1 1M 0F49h 2.66GHz/533MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

1, 4, 8, 12, 15, 19

SL9CK G1 1M 0F49h 2.66GHz/533MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

1, 4, 8, 12, 15, 19

SL8U4 G1 1M 0F49h 2.80GHz/533MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

1, 4, 8, 12, 15, 19

SL9CJ G1 1M 0F49h 2.80GHz/533MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

1, 4, 8, 12, 15, 19

SL8PP G1 1M 0F49h 2.80GHz/800MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

2, 4, 8, 11, 12, 15

SL9CG G1 1M 0F49h 2.80GHz/800MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

2, 4, 8, 11, 12, 15

SL8JX G1 1M 0F49h 2.80GHz/533MHz

35.0 x 35.0 mm

FC-mPGA4 Rev 2.0

2, 4, 7

SL9CD G1 1M 0F49h 2.93GHz/533MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

1, 4, 8, 11, 12, 15, 19

SL8PM G1 1M 0F49h 2.93GHz/533MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

4, 8, 12, 13, 14, 15, 19

SL8ZY G1 1M 0F49h 2.93GHz/533MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

4, 8, 11, 12, 13, 14, 15, 19

SL8ZZ G1 1M 0F49h 3.06GHz/533MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

4, 8, 11, 12, 13, 14, 15, 19
