Identification Information

Intel

Pentium

4 Processor on 90 nm Process Specification Update 29

Table 1. Intel

Pentium

4 Processor on 90 nm Process Processor Identification

Information

S-Spec

Core

Stepping

L2 Cache

Size (bytes) CPUID Speed Core/Bus Package and Revision Notes

SL8PY R0 2M 0F4Ah 3.80GHz/800MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

4, 5, 9, 11, 12, 13, 14, 15,

16, 18

SL8Q9 R0 2M 0F4Ah 3.80GHz/800MHz

775-land FC-LGA4

37.5 x 37.5 mm Rev 01

4, 5, 9, 11, 12, 13, 14, 15,

16, 17, 18

NOTES:

1. This is a boxed Intel Pentium 4 processor with an unattached fan heatsink.

2. Some of these processors are offered as boxed processors with an unattached fan heatsink.

3. These are engineering samples only.

4. These parts are multiple VIDs.

5. These parts will only operate at the specified core to bus frequency ratio and lower.

6. These Pentium 4 processors on 90 nm process support loadline A (FMB1.5).

7. These Pentium 4 processors on 90 nm process support loadline B (FMB1.0).

8. These Pentium 4 processors on 90 nm process in 775-land LGA package support the

775_VR_CONFIG_04A (mainstream) specifications.

9. These Pentium 4 processors on 90 nm process in 775-land LGA package support the

775_VR_CONFIG_04B (performance) specifications.

10. These parts have following specifications: VID = 1.475, Vmax = 1.370 V, Vmin = 1.290 V, VID = 1.500,

Vmax = 1.395 V, Vmin = 1.315 V and VID = 1.525, Vmax = 1.420 V, Vmin = 1.340 V, Icc_max = 55.9 A,

TDP = 68.4 W, Tcase = 75 °C, Isgnt = 23.0 A.

11. These parts support Hyper-Threading Technology.

12. These parts support Intel

Extended Memory 64 Technology.

13. These parts support Thermal Monitor 2 feature.

14. These parts support Enhanced Halt State.

15. These parts support Execute Disable Bit Feature.

16. These parts support Enhanced Intel SpeedStep

technology.

17. These parts support Intel

Virtualization Technology

18. These parts support minimum bus ratio of 12:1

19. This SKU was produced in limited quantity and is no longer available for purchase
