R91. A 64-Bit Value of Linear Instruction Pointer (LIP) May be Reported
Incorrectly in the Branch Trace Store (BTS) Memory Record or in the
Precise Event Based Sampling (PEBS) Memory Record
Problem: On a processor supporting Intel
®
EM64T,
• If an instruction fetch wraps around the 4G boundary in Compatibility Mode, the 64-bit value
of LIP in the BTS memory record will be incorrect (upper 32 bits will be set to FFFFFFFFh
when they should be 0).
• If a PEBS event occurs on an instruction whose last byte is at memory location FFFFFFFFh,
the 64-bit value of LIP in the PEBS record will be incorrect (upper 32 bits will be set to
FFFFFFFFh when they should be 0).
Implication: Intel has not observed this erratum on any commercially available software.
Workaround: None identified.
Status: For the steppings affected, see the Summary Tables of Changes.
R92. It is Possible That Two specific Invalid Opcodes May Cause Unexpected
Memory Accesses
Problem: A processor is expected to respond with an undefined opcode (#UD) fault when executing either
opcode 0F 78 or a Grp 6 Opcode with bits 5:3 of the Mod/RM field set to 6, however the
processor may respond instead, with a load to an incorrect address.
Implication: This erratum may cause unpredictable system behavior or system hang.
Workaround: It is possible for the BIOS to contain a workaround for this erratum.
Status: For the steppings affected, see the Summary Tables of Changes.
R93. At Core-to-bus Ratios of 16:1 and Above Defer Reply Transactions with
Non-zero REQb Values May Cause a Front Side Bus Stall
Problem: Certain processors are likely to hang the Front Side Bus (FSB) if the following conditions are
met:
1. A Defer Reply transaction has a REQb[2:0] value of either 010b, 011b, 100b, 110b, or 111b,
and
2. The operating bus ratio is 16:1 or higher.
When these conditions are met, the processor may incorrectly and indefinitely assert a snoop stall
for the Defer Reply transaction. Such an event will block further progress on the FSB.
Implication: If this erratum occurs, the system may hang. Intel chipsets avoid the REQb conditions required to
observe this erratum.
Workaround: None identified.
Status: For the steppings affected, see the Summary Tables of Changes.
