Intel Pentium 4 Processor on 90 nm Process

Specification Changes
R
Intel
®
Pentium
®
4 Processor on 90 nm Process Specification Update 73
Specification Changes
The Specification Changes listed in this section apply to the following documents:
• Intel
®
Pentium
®
4 Processor 670, 660, 650, 640, and 630
Δ
and Intel
®
Pentium
®
4 Processor
Extreme Edition Datasheet
• Intel
®
Pentium
®
4 Processors 570/571, 560/561, 550/551, 540/541, 530/531 and 520/521
Δ
Supporting Hyper-Threading Technology
1
Datasheet
All Specification Changes will be incorporated into a future version of the appropriate Pentium 4
processor documentation.
R1. Land Assignment Specification Change
The following lands have been reassigned as follows in the Intel
®
Pentium
®
4 Processor
670, 660, 650, 640, and 630
Δ
and Intel
®
Pentium
®
4 Processor Extreme Edition, Intel
Pentium 4 Processor Supporting Hyper-Threading Technology, Intel Pentium 4
Processor 570/571, 560/561, 550/551, 540/541, 530/531 and 520/521
Δ
Datasheet: On
90 nm Process in the 775-Land LGA Package Supporting Hyper-Threading Technology.
These reassignments have been made to facilitate compatibility with future processors.
These changes apply to the Land Listing and Signal Descriptions chapter in each of the
documents shown above.
Y3 from RESERVED to FC17
AE3 from RESERVED to FC18
B13 from RESERVED to FC19
E5 from RESERVED to FC20
AK6 from RESERVED to FC8
D23 from RESERVED to FC9
F6 from RESERVED to FC21
J3 from RESERVED to FC22
Δ Intel processor numbers are not a measure of performance. Processor numbers differentiate features within each processor
family, not across different processor families. Over time processor numbers will increment based on changes in clock, speed,
cache, FSB, or other features, and increments are not intended to represent proportional or quantitative increases in any
particular feature. Current roadmap processor number progression is not necessarily representative of future roadmaps. See
www.intel.com/products/processor_number for details.
§
