Intel Pentium 4 Processor on 90 nm Process

Summary Tables of Changes
R
Intel
®
Pentium
®
4 Processor on 90 nm Process Specification Update 9
O = Intel
®
Xeon
®
processor MP
P = Intel
®
Xeon
®
processor
Q = Mobile Intel
®
Pentium
®
4 processor supporting Hyper-Threading Technology on 90-nm
process technology
R = Intel
®
Pentium
®
4 processor on 90 nm process
S = 64-bit Intel
®
Xeon
®
Processor with 800 MHz system bus
T = Mobile Intel
®
Pentium
®
4 processor – M
U = 64-bit Intel
®
Xeon
®
processor MP with up to 8MB L3 Cache
V = Mobile Intel
®
Celeron
®
processor on 0.13 Micron Process in Micro-FCPGA Package
W = Intel
®
Celeron
®
M processor
X = Intel
®
Pentium
®
M processor on 90 nm process with 2-MB L2 cache
Y = Intel
®
Pentium
®
M processor
Z = Mobile Intel
®
Pentium
®
4 processor with 533 MHz system bus
AA = Intel
®
Pentium
®
processor Extreme Edition and Intel
®
Pentium
®
D processor on 65nm
process
AB = Intel
®
Pentium
®
4 processor on 65 nm process
AC = Intel
®
Celeron
®
Processor in 478 Pin Package
AD = Intel
®
Celeron
®
D processor on 65 nm process
AE = Intel
®
Core
TM
Duo Processor and Intel
®
Core
TM
Solo processor on 65nm process
NO. C0
1
D0 LD0
2
E0 LE0
2
G1
1
LG1
2
LN0
2
LR0
2
Plan ERRATA
R1 X X X X X X X X X
No
Fix
Transaction Is Not Retried after
BINIT#
R2 X X X X X X X X X
No
Fix
Invalid Opcode 0FFFh Requires a
ModRM Byte
R3 X X X X X X X X X
No
Fix
Processor May Hang Due to
Speculative Page Walks to Non-
Existent System Memory
R4 X X X X X X X X X
No
Fix
Memory Type of the Load Lock
Different from Its Corresponding
Store Unlock
R5 X X X X X X X X X
No
Fix
Machine Check Architecture Error
Reporting and Recovery May Not
Work As Expected
R6 X X X X X X X X X
No
Fix
Debug Mechanisms May Not
Function as Expected
R7 X X X X X X X X X
No
Fix
Cascading of Performance
Counters Does Not Work Correctly
When Forced Overflow Is Enabled
R8 X X X X X X X X X
No
Fix
EMON Event Counting of x87
Loads May Not Work As Expected
R9 X X X X X X X X X
No
Fix
System Bus Interrupt Messages
without Data Which Receive a
HardFailure Response May Hang
the Processor
