S2600GZ and S2600GL

Appendix B: Integrated BMC Sensor Tables Intel® Server Board S2600GZ/GL TPS
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/Readi
ng Type
Event Offset Triggers
Contrib. To
System Status
Assert/
De-
assert
Readable
Value/Of
fsets
Event
Data
Rearm
Stand-
by
Baseboard +3.3V Auxiliary
(BB +3.3V AUX)
D4h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Baseboard +1.05V Processor
1 Vccp
(BB +1.05Vccp P1)
D6h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.05V Processor
1 Vccp
(BB +1.05Vccp P2)
D7h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.5V P1 Memory
AB VDDQ
(BB +1.5 P1MEM AB)
D8h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.5V P1 Memory
CD VDDQ
(BB +1.5 P1MEM CD)
D9h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.5V P2 Memory
AB VDDQ
(BB +1.5 P2MEM AB)
DAh All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.5V P2 Memory
CD VDDQ
(BB +1.5 P2MEM CD)
DBh All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.8V Aux
(BB +1.8V AUX)
DCh All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.1V Stand-by
(BB +1.1V STBY)
DDh All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard CMOS Battery
(BB +3.3V Vbat)
DEh All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
