S2600GZ and S2600GL

Intel® Server Board S2600GZ/GL TPS Appendix B: Integrated BMC Sensor Tables
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/Readi
ng Type
Event Offset Triggers
Contrib. To
System Status
Assert/
De-
assert
Readable
Value/Of
fsets
Event
Data
Rearm
Stand-
by
Baseboard +1.35V P1 Low
Voltage Memory AB VDDQ
(BB +1.35 P1LV AB)
E4h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.35V P1 Low
Voltage Memory CD VDDQ
(BB +1.35 P1LV CD)
E5h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.35V P2 Low
Voltage Memory AB VDDQ
(BB +1.35 P2LV AB)
E6h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +1.35V P2 Low
Voltage Memory CD VDDQ
(BB +1.35 P2LV CD)
E7h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +3.3V Riser 1
Power Good
(BB +3.3 RSR1 PGD)
EAh
Platform
Specific
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Baseboard +3.3V Riser 2
Power Good
(BB +3.3 RSR2 PGD)
EBh
Platform
Specific
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A –
Hard Disk Drive 1 -15 Status
(HDD 1 - 15 Status)
F0h
-
FEh
Chassis-
specific
Drive Slot
0Dh
Sensor
Specific
6Fh
00 - Drive Presence
OK
As
and
De
– Trig Offset A X
01- Drive Fault
Degraded
07 - Rebuild/Remap in
progress
Degraded
Revision 2.4 209
