S2600GZ and S2600GL

System Security Intel® Server Board S2600GZ/GL TPS
Main
Advanced
Security
Server Management
Boot Options
Boot Manager
Administrator Password Status
<Installed/Not Installed>
User Password Status
<Installed/Not Installed>
Set Administrator Password [1234aBcD]
Set User Password [1234aBcD]
Front Panel Lockout Enabled/
Disabled
TPM State
<Enabled & Activated/Enabled & Deactivated/Disabled &
Activated/Disabled & Deactivated>
TPM Administrative Control
No Operation/
Turn On/Turn Off/Clear Ownership
Figure 31. Setup Utility – TPM Configuration Screen
Table 19. TPM Setup Utility – Security Configuration Screen Fields
Setup Item
Options
Help Text
Comments
TPM State*
Enabled and Activated
Enabled and Deactivated
Disabled and Activated
Disabled and
Deactivated
Information only.
Shows the current TPM device state.
A disabled TPM device will not execute
commands that use TPM functions and
TPM security operations will not be
available.
An enabled and deactivated TPM is in
the same state as a disabled TPM
except setting of TPM ownership is
allowed if not present already.
An enabled and activated TPM
executes all commands that use TPM
functions and TPM security operations
will be available.
TPM
Administrative
Control**
No Operation
Turn On
Turn Off
Clear Ownership
[No Operation] - No changes to current
state.
[Turn On] - Enables and activates TPM.
[Turn Off] - Disables and deactivates TPM.
[Clear Ownership] - Removes the TPM
ownership authentication and returns the
TPM to a factory default state.
Note: The BIOS setting returns to [No
Operation] on every boot cycle by default.
