System BIOS Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
102
Server Management
System Information
Board Part Number
Board Serial Number
System Part Number
System Serial Number
Chassis Part Number
Chassis Serial Number
BMC Firmware Revision
HSC Firmware Revision
SDR Revision
UUID
Figure 31. Setup Utility — Server Management System Information Screen Display
Table 44. Setup Utility — Server Management System Information Fields
Setup Item Options Help Text Comments
Board Part Number Information Only
Board Serial Number Information Only
System Part Number Information Only
System Serial Number Information Only
Chassis Part Number Information Only
Chassis Serial Number Information Only
BMC Firmware Revision Information Only
HSC Firmware Revision Information Only
SDR Revision Information Only
UUID Information Only
5.2.3.6 Boot Options Screen
The Boot Options screen displays any bootable media encountered during POST, and allows
the user to configure desired boot device.
To access this screen from the Main screen, choose Boot Options.
