Intel® Server SE7520BD2SCSI Errata and Contingencies
November 2, 2004 13
Operating system
(Windows XP, Windows 2000, etc.)
Failure type
(Contingency, Errata, Incident)
ID number
Windows 2003 Enterprise
Edition
Errata 901
Failing test name
ACPI Verifier
Applicable error message
(Type N/A if the error message
or failing text is excessive or if
there is no text)
| The memory range specified is in conflict with the system's E820 table.
| The E820 table says that this memory range is in the
AcpiAddressRangeMemory range
| which is conflicting with the requested memory range which is
| between 0x0 - 0x9d800
Additional information
(for example, test system in a
multiple system configuration)
The ACPI Verifier test falsely fails test systems that have
AcpiAddressRangeMemory conflicts in the E820 table in the following cases:
Additional Information
• Due to Windows 2003 Enterprise Server operating system limitations, server systems
that support 4GB or more of memory are tested with maximum memory installed for all
HCTs with PAE enabled except for the ACPI HCTs where PAE is not enabled in order to
bring the total system memory below 4GB to enable the system to go into hibernation.
Refer to errata ID: 92.
