Report

Errata and Contingencies Intel® Server Board SCB2 ATA
12 January 22, 2003
Testing Exceptions for Intel® Server Board SCB2 ATA Update Submission
Data in this section reflects product data and test exceptions listed in section 2 of the Intel® Server
Board SCB2 ATA Readme file at time of WLP Update submission.
Operating system
(Windows XP, Windows 2000, etc.)
Failure type
(Contingency, Errata, Incident)
ID number
Windows 2000 Errata 702
Failing test name
DSound, Full Duplex, Mixer Driver, Wave Driver
Applicable error message
(Type N/A if the error message or
failing text is excessive or if there is
no text)
Servers that do not ship with an audio device are not required to run the following
audio tests:
• Direct Sound Driver
• Full Duplex
• Mixer Driver
• Wave Driver
Refer to errata 702 titled: Audio tests are not required for servers that do not
implement audio devices
Additional information
(for example, test system in a
multiple system configuration)
Operating system
(Windows XP, Windows 2000, etc.)
Failure type
(Contingency, Errata, Incident)
ID number
Windows 2000 Errata 722
Failing test name
PCI 2.1 (Cards) Test
Applicable error message
(Type N/A if the error message or
failing text is excessive or if there is
no text)
Errata Title: PCI 2.2 Compliance test and PCI 2.1 (Cards) test might fail test systems
with ATA/ATAPI controllers
Problem:
PCI2.1 (Cards) test fails with the following error:
Getting the resource Length.
BAR is 0xFFBFFC00, Length of BAR is 0x00000400
ERROR: Base register 24 should be zero (read-only)!
Additional information
(for example, test system in a
multiple system configuration)
Additional Information for Udpate Submission
Data in this section reflects product data and additional information entered in section 3 of the Intel®
Server Board SCB2 ATA Readme file at time of WLP submission.
• Due to Windows* 2000 Advanced Server* operating system limitations server systems that support
4GB or more of memory are tested with maximum memory installed for all HCTs except for the
ACPI HCTs. Memory is removed in order to bring the total system memory below 4GB to enable
Windows 2000 Advanced Server to go into hibernation. Refer to errata ID: 92 and the AWE Test
procedures for more information.
