Report

Errata and Contingencies Intel® Server Board SCB2 ATA
14 January 22, 2003
Operating system
(Windows XP, Windows 2000, etc.)
Failure type
(Contingency, Errata, Incident)
ID number
Windows 2000 Errata 298
Failing test name
PCI Power Management Register Interface
Applicable error message
(Type N/A if the error message or
failing text is excessive or if there is
no text)
Errata Title: PCI Power Management Register Interface Test: False Failure
Log File: pcicap.log
Problem:
Following errors occurs in the PCICAP log file:
<<< FAILED 4.4.2 >>>
PowerState field in PMCSR register is not writable.
Solution:
Refer to Errata 298 for details of above acceptable failure.
Additional information
(for example, test system in a
multiple system configuration)
Operating system
(Windows XP, Windows 2000, etc.)
Failure type
(Contingency, Errata, Incident)
ID number
Windows 2000 Errata 670
Failing test name
Preview PCI Pre-OS Tests (PME# Signal Routing, 3.3 Vauv Auxiliary Power Load,
Simultaneous PME# Signal Assert)
Applicable error message
(Type N/A if the error message or
failing text is excessive or if there is
no text)
Preview PCI Pre-OS Test failures are acceptable. Preview PCI Pre-OS tests are not
required to pass with HCT 9.502 on systems with any number of PCI slots. The
SCB2 SCSI system has 2 available PCI slots.
The following Preview PCI Pre-OS Tests failures are acceptable per errata 670:
• PME# Signal Routing[Preview] acceptable failure
• 3.3Vaux Auxiliary Power Load[Preview] acceptable failure
• Simultaneous PME# Signal Assert[Preview] acceptable failure
Refer to errata 670 titled: PCI Pre-OS tests are no longer required, depending on the
number of PCI slots in the test system
Additional information
(for example, test system in a
multiple system configuration)
Operating system
(Windows XP, Windows 2000, etc.)
Failure type
(Contingency, Errata, Incident)
ID number
Windows 2000 Errata 683
Failing test name
Parallel Test
Applicable error message
(Type N/A if the error message or
failing text is excessive or if there is
no text)
Parallel test not required for systems that ship without a parallel port. Refer to errata
titled: Parallel port and LPT PnP Enumeration tests not required for systems and
servers without parallel ports
Additional information
(for example, test system in a
multiple system configuration)
