MODEL P1251P

PORTABLE TWO CIRCUIT OUTDOOR

TIMER WITH GROUND FAULT PROTECTION.

TOTAL LOAD NOT TO EXCEED: 15A. RESISTIVE, 1800W (15A.)

TUNGSTEN, 1 HP (15 FLA, 90 LRA) - 120 VOLT 60 HZ.

TIMED & PHOTO CONTROL LOAD: 900W 120 VOLT 60 HZ.

Suitable for Outdoor Use, Pool/Spa Equipment Control

IMPORTANT

GFCI TEST PROCEDURE

The GFCI should be checked every month to make sure it is operating

properly. It is recommended that a permanent record of the monthly

safety check is maintained.

1. Push TEST button. RESET button should pop out from

inner surface. This should result in power being OFF at the

outlets. Verify by plugging test lamp into TIMED outlet. Be

sure the timer is in the ON position.

2. If the GFCI tests okay, restore power by pushing the RESET

button back in. THE RESET BUTTON MUST BE PUSHED

FIRMLY AND FULLY INTO PLACE UNTIL IT LOCKS AND

REMAINS DEPRESSED AFTER PRESSURE HAS BEEN

REMOVED.

DANGER IF RESET BUTTON DOES NOT POP OUT, IF TEST

LAMP REMAINS LIT WHEN RESET BUTTON DOES POP OUT,

OR IF GFCI FAILS TO RESET PROPERLY, DO NOT USE

TIMER! CONTACT A QUALIFIED SERVICE TECHNICIAN!

TIMER - OPERATING INSTRUCTIONS

TIMED OUTLET: is controlled ONLY by the timer.

TIMED & PHOTO CONTROLLED OUTLET: need both Photo

Control and Timer to be activated for the load to turn on. The load

will turn off when either the Photo Control or Timer is deactivated.

1. Insert ON (GREEN) and OFF (RED) trippers into dial at

desired ON and OFF times.

2. Turn dial clockwise and align arrow with Time-of-Day (AM or

PM) in window.

3. Plug Pump into TIMED outlet.

4. Plug Light into TIMED & PHOTO CONTROL outlet.

FOR TEMPORARY MANUAL OPERATION

Rotate MANUAL knob counter-clockwise to desired ON or

OFF position. Timer will follow next automatic operation.

INTERMATIC INCORPORATED

SPRING GROVE, ILLINOIS 60081-9698

154--00876 PRODUCT OF MEXICO

This portable timer is designed for CONTROLLING the

connected equipment only. Unplug timer before servicing

the unit or the equipment it controls. THIS DEVICE IS NOT

TO BE USED AS A POWER DISCONNECT! For maximum

protection against electrical shock hazard, perform test

procedure on GFCI at least once a month. If used to

control pool/spa equipment install at least 5 feet from inside

edge of pool/spa.

LR3730
