Hotkey Commands
*This function can ONLY be used if you have physically connected one computer to the LCD Console.
If you have connected multiple computers to the LCD Console through a KVM such as GCS1808/
GCS1716, you would need to enable the SUN Keyboard Emulation from the KVM, please see the user
manual for the specic KVM for details.
Combination Description
[Ctrl][Alt][Shift][P][C][Enter] Set keyboard operating platform to PC compatible
[Ctrl][Alt][Shift][S][U][N][Enter] Set keyboard operating platform to SUN compatible*
[Ctrl][Alt][Shift][M][A][C][Enter] Set keyboard operating platform to MAC compatible*
[Ctrl][Alt][Shift][U][P][G][R][A][D][E][Enter] Trigger Firmare Upgrade Mode
[Ctrl][Alt][Shift][L][Enter] Enable Internal Console and disable External
Console
[Ctrl][Alt][Shift][R][Enter] Enable External Console and disable Internal
Console
[Ctrl][Alt][Shift][L][R][Enter] or
[Ctrl][Alt][Shift][R][L][Enter]
Enable both Internal Console and External Console
