Display (VGA) Extender Video Display Extender over Cat Cable User Manual (GVE120) ®
The GVE120 Video Display Extender allows you to extend the distance between the computer system unit and the VGA display over 400 feet (130 meters) away. It accomplishes this by means of a local transmitting unit (GVE120L), and a remote receiving unit (GVE120R), connected by standard Category 5, 5e, or 6 twisted pair Ethernet cable. We hope you enjoy using your Video Extender, yet another first-rate connectivity solution from IOGEAR®. © 2003 IOGEAR®. All Rights Reserved.
Table of Contents Package Contents.................................................................................................................................. Overview................................................................................................................................................. Features................................................................................................................................................. Requirements...........................
Package Contents This package contains: 1- IOGEAR Video Extender (GVE120) • Remote Unite (GVE120R) • Local Unite (GVE120L) 1- VGA (HD15) male - VGA (HD15) male / 6 feet cable 2- 9V 500ma Power Adapter 1- Quick Start Guide 1- Warranty / Registration Card If any of the items are missing or damaged, please contact your dealer immediately.
Overview The GVE120 Video Display Extender is ideal for factory and construction sites, or any installation where the display needs to reside in a harsh settings while you and your system equipment are in an environmentally friendly location. The Video Extender is also useful for control and security purposes, where you can have the system unit in a secure area at the same time that you put the display in an area that is convenient for viewing.
Features • • • • • • • Superior Video Quality, Maintains Highest Signal Strength In All Applications Up to 1600 x 1200 @ 300 feet Supports VGA, SVGA, and Mutisync Compatible Displays Hassle free, no software to install, instant installation and use.
Requirements VGA, SVGA, Multisynce Compatible Macintosh Users: • All MACs With Analog VGA Support PC Users: • All PCs With Analog VGA Support Accessories / Additional Products VGA Video Splitter – (2-port/GVS92, 4-port/GVS94, 8-port/GVS98) USB Flex™ Web Cam - USB Flaxable Web Camera (GCA210U) KVMP Switch – 2 and 4 port USB KVMP switch (GCS1712/14) 5
Introduction IIntroducing the easiest way deliver your computers video signal over great distances! IOGEAR’s® Video Display Extender is a unique way bring your monitors signal to places usually out of reach. Send live, streaming video across the home or workplace. The IOGEAR’s® Video Display Extender is perfect for use in class rooms, conference and training rooms, and other sites that require video to be displayed at distant locations.
Introduction This manual contains information on the installation and capabilities of your new IOGEAR’s® Video Display Extender In sections of the manual where sequential steps are listed, each action is listed with no indentation. Additional text is included, but indented, to further explain each of these actions. A glossary has been added at the end of the manual so you may look up unfamiliar terms.
Pictorial Introduction – Local Unit (GVE120) Local Unite (GVE120) 2 3 4 1 5 6 1. 2. 3. 4. 5. 6. 7.
Pictorial Introduction – Local Unit (GVE120) Range Switch Slide the switch to the Long position if the Remote Unit is located a long distance away; slide the switch to the Short position if the Remote Unit is located a short distance away. Remote I/O The Category 5, 5e, or 6 twisted pair ethernet cable that connects to the Remote Unit plugs into this connector.* Power Port (AC 9V) The power supply cable plugs into this connector. Power Indicator Light Lights to indicate that the unit is receiving power.
Pictorial Introduction – Remote Unit (GVE120R) Remote Unite (GVE120R) 2 3 4 1 5 1. 2. 3. 4. 5.
Pictorial Introduction – Remote Unit (GVE120R) Remote I/O The Category 5, 5e, or 6 twisted pair cable that connects to the Local Unit plugs into this connector. Power Port (AC 9V) The power supply cable plugs into this connector. Power Indicator Light Lights to indicate that the unit is receiving power. Monitor Port The remote monitor’s VGA cable plugs into this connector.
Installation of Video Extender Warning! Make absolutely sure that a protective ground wire with no potential difference is established between the AC sources for the Local and Remote units. Unequal grounding potential between the Local and Remote units will result in damage to the units and connected devices. Refer to the pictorial introduction as you follow the step-by-step directions below: 1. Make sure that the computer and monitors you are using for the installation are powered Off. 2.
Installation of Video Extender 3. Plug the local monitor’s VGA cable into the Local Unit’s Monitor port. 4. Plug one of the power adapters (supplied with this package) into your surge protector power strip; plug the adapter’s power cable into the Local Unit’s Power Port. 5. Plug one end of your selected Category 5, 5e, or 6 twisted pair cable into the Local Unit’s Remote I/O port.
Installation of Video Extender 6. Slide the Range Switch to the Long position if the Remote Unit location is a long distance away; slide the switch to the Short position if the Remote Unit location is a short distance away. 7. Plug the other end of the Category 5, 5e, or 6 twisted pair cable into the Remote Unit’s Remote I/O port.
Installation of Video Extender 8.Plug the remote monitor’s VGA cable into the Remote Unit’s Monitor port. 9.Plug the second power adapter (supplied with this package) into a remote surge protector power strip; plug the adapter’s power cable into the Remote Unit’s Power Port. 10.Power On the computer and monitors. Note: Refer to the Cable Length table in the Technical Details section on page ___ for typical resolution/ refresh rate/distance ratios.
Technical Details TP Pin Assignments Cable Length 16
Technical Details TP Wiring Diagram 17
Technical Support To help IOGEAR® customers obtain the highest level of performance from their IOGEAR® Video Display OSD OperaExtender, IOGEAR® Service Support team is available to answer your technical questions. Do not hesitate tion to call if you are having trouble getting your drive to work correctly. Service Support can be reached at IOGEAR® from 8am to 5pm Pacific Standard Time, Monday through Friday or at the following address: 23 Hubble Drive Irvine, CA 92618 You may also reach us online at www.
Specification 19
Radio & TV Interference Statement WARNING!!! This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. This equipment has been tested and found to comply with the limits for a Class B computing device pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR’S LIABILITY FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK, OR ITS DOCUMENTATION EXCEED THE PRICE PAID FOR THE PRODUCT. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and especially disclaims its quality, performance, merchantability, or fitness for any particular purpose.
