Specification Sheet

Deluxe Adjustable Swivel
Electric Ironing Center | AE-42
Product Specification Packet
February 2021
SIDE VIEW
TOP VIEW
FRONT VIEW
OVERALL SIZE
Cabinet Height 52”
Cabinet Width 15”
Cabinet Depth* 7 3/4”
Door Size 52” H x 15” W x 3/4” D
ROUGH-IN OPENING
Height 51 1/4”
Width 14 3/8”
Depth* 3 7/8”
DEPTH INTO ROOM
Recessed* 3 7/8”
Surface Mount* 7 3/4”
CABINET FACE FRAME OVERLAP
WHEN RECESSING
Overlap 3/8”
Product Dimensions
Installation Heights
MOUNTING
HEIGHT
ABOVE FLOOR
DESIRED
IRONING
HEIGHT
ADJUSTED
POSITION
HEIGHT
29” 36” 40”
28” 35” 39”
27” 34” 38”
26” 33” 37”
25” 32” 36”
Page 1 of 3
*Depth includes door
Note: The ironing board automatically engages to lower position each
time the board is lowered for use. Higher position requires adjustment
and engages back to low position each time the board is put away.
