Installation Manual

All Tile Hook Flashing

9.0

14.0

1.14

.02

NO.

DESCRIPTION

FLASHING, ALL TILE HOOK, MILL

WEIGHT: LBS

SHEET 1 OF 1

SIZE

SCALE:1:8

DO NOT SCALE DRAWING

FLASHING, ALL TILE HOOK,

MILL

PAGE 1
All Tile Hook Flashing 1 9.0 14.0 1.14 .02 NO. 1 DESCRIPTION FLASHING, ALL TILE HOOK, MILL © 2018 IronRidge, Inc. All rights reserved. Visit www.ironridge.com or call 1-800-227-9523 for more information. FLASHING, ALL TILE HOOK, MILL SIZE DO NOT SCALE DRAWING A SCALE:1:8 WEIGHT: LBS SHEET 1 OF 1 ATHF-MAN REV 1.
PAGE 2
All Tile Hook Flashing Installation Tools and Materials Required: caulking gun, roofing mastic, trowel or applicator, and fabric reinforcement 1 2 Sealant Apply a continuous line of roofing manufacturer’s approved sealant on underside of the All Tile Hook flashing to form a U shape around raised edges. 3 Position the flashing over the base of All Tile Hook so that the flashing completely covers the base.
