Expand Your Factory Radio add Harness Connection Port 1 a Port 2 a a Dip Switches (See Manual) Satellite Radio a USB a Honda/Acura Owner’s ISHD11 Manual Owner’s Manual Media Gateway PGHHD1 Media Gateway PXAMG iSimple® A Division of AAMP of America™ 13190 56th Court Clearwater, FL 33760 Ph. 866-788-4237 support@isimplesolutions.com ©2009 AAMP of Florida, Inc. www.isimplesolutions.com Rev.
Table of Contents 1. 2. 3. 4. 5. 8. Introduction Precautions Compatibility Notes Dipswitch Settings Installation Sirius Satellite Radio Operation 8. Selecting AUX Input 10. Troubleshooting 11.
Media Gateway & Optional Add-ons *The Media Gateway will only support 2 inputs.
1. Introduction ® Thank you for purchasing the iSimple Media Gateway. The Media Gateway is designed to provide endless hours of listening pleasure from your factory radio. To ensure that your SCC1 satellite radio tuner performs correctly with your radio, we recommend that you read this entire manual before attempting installation of the Media Gateway.
3. Compatibility Your vehicle MUST either be equipped with, or have the ability to support Satellite Radio. Please visit www.isimplesolutions.com for the most up to date application information and to verify your vehicle’s compatibility. 4. Dipswitch Settings All 4 dipswitches MUST be set in the OFF (up) position for proper operation.
5. Installation 1. When making electrical connections it is always recommended that the vehicle’s battery be disconnected from the electrical system before performing the installation. 2. Carefully remove the trim panels covering the 8mm bolts that secure the radio into the dash cavity. Remove these bolts, and carefully pull the radio from the dash of the vehicle. This will provide access to the factory radio connectors where you will connect the Media Gateway harness. 3.
8. Sirius Satellite radio Operation Entering Mode Select Menu Press the “AM-FM” button then press the “XM or “AUX” button. Turn the rotary TUNE KNOB or press “TUNE ▲” until “SIRIUS” is displayed. The PXAMG will auto select the mode after 6 seconds of inactivity.
10. Troubleshooting Symptom Cause Remedy I don’t see artist or song information on the screen The radio is Press the Text / Scan button to see displaying a different text text field The Media Gateway does not recognize the Satellite Radio tuner (SCC1) The Satellite tuner was not properly connected when the PXAMG was first connected and initialized. SCC1 must be connected before the PXAMG is powered on. Disconnect the PXAMG from the vehicles harness for 5 minutes.
11. Warranty One Year Limited Warranty The quality controls used in the manufacture of this product will ensure your satisfaction. This warranty applies only to the original purchaser of this product from an authorized iSimple® dealer. This warranty covers any supplied or manufactured parts of this product that, upon inspection by iSimple® authorized personnel, is found to have failed in normal use due to defects in material or workmanship. This warranty does not apply to installation expenses.
Notes ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ___________
Notes ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ___________
www.isimplesolutions.com For Best Performance Have It Professionally Installed.
