INTRODUCTION Congratulations on your purchase of the IMPRESSION™ Pedal. The IMPRESSION Pedal was designed to provide ease of use for the most common DSP based effects while providing high quality Stereo effects processing for Chorus, Flange, Delay and Reverb. The IMPRESSION allows the use of 3 effects simultaneously including Chorus or Flange plus Delay and Reverb. The IMPRESSION includes a TAP function allowing on the fly adjustment of the Chorus modulation time, Flange modulation time and Delay time.
IMPRESISON™ PEDAL CONTROLS 1. DIRECT LEVEL MIX Control: Adjusts the level of the instrument direct level. This will set the amount of direct instrument fed in the output mix. If using the IMPRESSION Pedal in a parrallel effects loop turn this control full counterclockwise. This control can also be used as a main level control for the direct signal level of your rig. 2. EFFECT LEVEL MIX Control: Adjusts the mix level of the IMPRESSION effects. 3. CHORUS ACTIVE LED: Lights when the Chorus effect is active.
consecutive TAP’s of the switch. If mapped to DELAY it will set the DELAY time up to a maximum of 800 milliseconds in length based on the TAP time between two consecutive TAP’s of the switch. IMPRESSION PEDAL REAR PANEL The rear panel has 3 ¼ inch phone jacks with one for the instrument input and two for the final stereo output signals Left and Right. Power is connected via a barrel connector labeled 9VAC.
IMPRESSION PEDAL SPECIFICATIONS Input Impedance Maximum Input Level Maximum Output Level Dynamic Range Decimator Effective Noise Reduction Noise Floor / Mix Level at ½ CHORUS Modulation Time FLANGE Modulation Time Maximum DELAY Time Reverb Mix Dimensions Weight Power Power Consumption 560k ohms +11dbu +11dbu 93db A weighted 12db -90dbu User Set up to 5 seconds User Set up to 5 seconds 800 milliseconds User Set from Odb to -21db 7.4”L x 4.7”W x 1.42”H 1.
