Front & Rear Panel
① Power LED: The LED illuminates red when power is applied.
② INPUT LED: The LED illuminates blue when there is HDMI input
③ INPUT: Type-A female HDMI input port to connect the HDMI source.
④ SCALER ON/OFF: Turn on or off the down-scaling function.
⑤ FW: Micro-USB port for firmware upgrade.
⑥ OUTPUT LEDS: Two LEDS illuminate blue when there are HDMI outputs.
⑦ OUTPUTS: Two type-A female HDMI output ports to connect HDMI displays
2
PANEL DESCRIPTION
1
2
3
4
5
7
6
Out 1
Out 2
In
Downscale
On/Off FW/DC 5V
