Dimensions Guide

Comfort™ Collection Technical Specications Manual
QA61000 www.jacuzzi.com TechnicalSpecications
Capella® 6060 Whirlpool And Soaking Skirted Bathtubs
Key Dimensions
Letter Description Whirlpool Soaking
-
DrainLocation CenterDrain
-
WhirlpoolPumpLocation RightHand N/A
-
Cutout N/A
-
TotalWeight 1152 lb (523 kg) 1131 lb (513 kg)
-
FloorLoading 46lb/ft
2
(225 kg/m
2
) 45lb/ft
2
(220 kg/m
2
)
-
OperatingGallons(Min/Max) 52Gal(197L)/84Gal(318L)
-
ProductWeight 152lb(69kg) 131lb(59kg)
L
OuterLength 60.00" (1524 mm)
W
OuterWidth 60.00" (1524 mm)
H
OverallHeight 21.50" (546 mm)
A
OverowHeight 19.50"(495mm)
B
LongEdgetoDrainCenter 12.13"(308mm)
C
ShortEdgetoDrainCenter 34.94"(887mm)
D
DrainShoeLength 9.50"(241mm)
E
FlangeHeight 1.00" (51 mm)
F
DeckWidth 3.75"(95mm)
G
ServiceAccess SeeIllustrationBelow N/A
I
FloorCutoutforDrain 12.00x4.00"(305x102mm)
J
InteriorDimensions:
J(W)xJ(L)
34.00x50.00"(864x1270mm)
NOTE
Theoveralldimensionsarenominalwithatoleranceof+0and-.25”(6mm).
ElectricalSpecications
(Eachcomponentrequiresaseparate,dedicatedGFCIprotectedcircuit)
Motor/Pump  120V15A60HZ
Heater(optional)  120V15A60HZ
 (CenterDrain/RightSideWhirlpoolPumpshown)
Drain/Overow
D
A
B
NOTE:Drawingsnottoscale.
Corner Soaking Skirted Bathtub
*Deckwidthreectsonlyareaindicatedondetail.
EndViewFrontView
C
I
C
L
F
27.00"
43.13"
L
J(W)
J(L)
27.00"
46.63"
6"
L
J(L)
J(W)
C
I
6"
Heater
L
C
27.00"
27.00"
46.63"
43.13"
F
Whirlpool
Pump
Service
Access
Panel
L
Heater
Whirlpool
Motor
E
Whirlpool
Motor
W
H
20.50
