Milan 35.4" Single Vanity Cabinet

Diagrams with Dimensions

page 01 of 03

NOTE ONE: Countertops are not shown in these diagrams. (Cabinet Only)

NOTE TWO: This vanity does not have a Backsplash.

Please consult our website for Countertop Diagrams: www.jamesmartinvanities.com

Version:202011

Item Number:

801-V35.4-GW

801-V35.4-WLT

801-V35.4-MGG

35.4"

35 3/8"

33 3/4"

15 3/4"

20"
