Specification

Frame Size
Rough Opening
Daylight Opening Daylight Opening
Unit Size
2 11/16"
1 7/8"13/16"
1/2"
11/16"
1 3/16"
3/4"
11/16"
1"
1"
1 3/16"
2 11/16"
1 7/8"13/16"
3/4"
11/16"
1"
Scale: 6" = 1' - 0"
10
Architectural Design Manual
February 2017
Product specifications may change without notice.
Questions? Consult JELD-WEN customer service.
BUILDERS ALUMINUM
ALUMINUM WINDOWS
SLIDER
SLIDE ON NAIL FIN - VERTICAL SECTION
