Fixed, Radius and Geometric Windows Premium Vinyl PRODUCT SPECIFICATIONS MATERIALS GRILLES Extruded vinyl profiles comply with the performance requirements of AAMA 303-97. Colors are White and Desert Sand. Available in the West. SDL (Simulated Divided Lite) - 7/8“ (23mm), 1-1/8“ (29mm), 1-3/8“ (35mm), or 2-1/8” (58mm) contour grilles surface mounted on the exterior surfaces of the insulating glass, with shadow bars mounted between the glass panes suspended within the air cavity.
Fixed, Radius and Geometric Windows Premium Vinyl QUICK SPEC GUIDE SPECIFICATION COLOR S White SIZE (Rough Opening) S S S Width: 12” to 108” S Integral Nail Fin FRAME GLAZING S Architectural Detail Manual July 2010 S S Desert Sand S S Integral Dual Wall Flush Fin S Pocket/Block Frame S S S S S Low-E S S S 1” Contour GBG (grilles between the glass) Height: 12” to 108” 50 sq.
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) 19 3/4”(502) 18”(457) 17 1/2”(445) 13 7/8”(352) 13 3/4”(349) 12”(305) 11 1/2”(292) 7 7/8”(200) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 13 3/4”(349) 19 3/4”(502) 12”(305) 18”(457) 11 1/2”(292) 17 1/2”(445) 7 7/8”(200) 13 7/8”(352) 35 PPC1212 35 PPC1218 35 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) PPC1224 35 PPC1230 35 PPC1812 35 PPC1818 35 PPC1824 35 PPC1830 35 25
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 13 3/4”(349) 12”(305) 11 1/2”(292) 7 7/8”(200) 35 23 3/4”(603) 22”(559) 21 1/2”(546) 17 7/8”(454) 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) 35 35 PPC2260 PPC2460 35 35 PPC2266 PPC2466 35 35 PPC2272 PPC2472 35 35 PPC2278 PPC2478 35 35 PPC2284 PPC2484 27 3/4”(705) 26”(660) 25 1/2”(648) 21 7/8”(556) 35 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) 33 3/4”(857) 3
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 13 3/4”(349) 12”(305) 11 1/2”(292) 7 7/8”(200) 35 23 3/4”(603) 22”(559) 21 1/2”(546) 17 7/8”(454) 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) 35 35 PPC2290 PPC2490 35 35 PPC2296 PPC2496 27 3/4”(705) 26”(660) 25 1/2”(648) 21 7/8”(556) 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) 35 35 33 3/4”(857) 32”(813) 31 1/2”(800) 27 7/8”(708) 35 3/4”(908) 34”(864) 33 1/2”(851) 29
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) 39 3/4”(1010) 38”(965) 37 1/2”(953) 33 7/8”(860) 35 35 PPC3612 PPC3812 35 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) 35 PPC3830 35 PPC3636 PPC3836 35 35 35 PPC5424 PPC4830 PPC4236 35 35 PPC5430 35 PPC4836 35 35 PPC5436 35 35 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) 35 PPC5418 PPC4824 PPC4230 35 35 35 35 PPC5412 PPC4818 PPC4224 35 35 35 35 PPC3
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) 39 3/4”(1010) 38”(965) 37 1/2”(953) 33 7/8”(860) 35 49 3/4”(1264) 48”(1219) 47 1/2”(1207) 43 7/8”(1114) 35 55 3/4”(1416) 54”(1372) 53 1/2”(1359) 49 7/8”(1267) 35 35 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 35 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) PPC3660 PPC3860 35 PPC4860 35 PPC5460 35 35 67 3/4”(1721) 66”(1
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) 39 3/4”(1010) 38”(965) 37 1/2”(953) 33 7/8”(860) 35 49 3/4”(1264) 48”(1219) 47 1/2”(1207) 43 7/8”(1114) 35 55 3/4”(1416) 54”(1372) 53 1/2”(1359) 49 7/8”(1267) 35 35 91 3/4”(2330) 90”(2286) 89 1/2”(2273) 85 7/8”(2181) 35 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) PPC3690 PPC3890 35 PPC4890 35 PPC5490 35 35 97 3/4”(2483) 96”(2
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) 35 PPC6012 19 3/4”(502) 18”(457) 17 1/2”(445) 13 7/8”(352) 13 3/4”(349) 12”(305) 11 1/2”(292) 7 7/8”(200) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 35 PPC6612 35 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) PPC6018 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) PPC7218 PPC6624 PPC6030 35 PPC7224 35 PPC7230 35 PPC
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) 35 35 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 35 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) PPC6060 PPC6660 PPC7260 35 35 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) 35 PPC6066 PPC6666 35 35 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) 35
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) 35 35 91 3/4”(2330) 90”(2286) 89 1/2”(2273) 85 7/8”(2181) 35 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) PPC6090 PPC6690 35 35 97 3/4”(2483) 96”(2438) 95 1/2”(2426) 91 7/8”(2334) 35 PPC7290 PPC6096 PPC6696 PPC7296 ELEVATION SYMBOL LEGEND: VALUES IN () ARE IN MILLIMET
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS 79 3/4”(2026) 78”(1981) 77 1/2”(1969) 73 7/8”(1876) 85 3/4”(2178) 84”(2134) 83 1/2”(2121) 79 7/8”(2029) 35 PPC7812 91 3/4”(2330) 90”(2286) 89 1/2”(2273) 85 7/8”(2181) 35 PPC8412 19 3/4”(502) 18”(457) 17 1/2”(445) 13 7/8”(352) 13 3/4”(349) 12”(305) 11 1/2”(292) 7 7/8”(200) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 35 PPC9012 35 PPC8418 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) PPC7818 35 PPC7824 35 31 3/4”(806) 30
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 79 3/4”(2026) 78”(1981) 77 1/2”(1969) 73 7/8”(1876) 85 3/4”(2178) 84”(2134) 83 1/2”(2121) 79 7/8”(2029) 35 35 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 35 91 3/4”(2330) 90”(2286) 89 1/2”(2273) 85 7/8”(2181) PPC7860 PPC8460 PPC9060 35 35 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) 35 PPC7866 PPC8466 35 35 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) 35
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 79 3/4”(2026) 78”(1981) 77 1/2”(1969) 73 7/8”(1876) 91 3/4”(2330) 90”(2286) 89 1/2”(2273) 85 7/8”(2181) 35 PPC7890 ELEVATION SYMBOL LEGEND: VALUES IN () ARE IN MILLIMETER CONVERSIONS ## INDICATES DESIGN PRESSURE (DP) RATING WITH STANDARD GLAZING Note: Elevations shown DO NOT have exterior trim. Subtract 1/2”(12.7) from M.O.(Masonry Opening) for Unit Sizes.
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE UNITS 97 3/4”(2483) 96”(2438) 95 1/2”(2426) 91 7/8”(2334) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 97 3/4”(2483) 96”(2438) 95 1/2”(2426) 91 7/8”(2334) PPC9612 35 35 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 35 19 3/4”(502) 18”(457) 17 1/2”(445) 13 7/8”(352) 13 3/4”(349) 12”(305) 11 1/2”(292) 7 7/8”(200) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) PPC9618 35 PPC9660
Fixed, Radius and Geometric Windows Premium Vinyl QUARTER ROUND PQR1818 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) PQR2222 PQR2626 35 3/4”(908) 34”(864) 33 1/2”(851) 29 7/8”(759) 33 3/4”(857) 32”(813) 31 1/2”(800) 27 7/8”(708) PQR3232 PQR3434 39 3/4”(1010) 38”(965) 37 1/2”(953) 33 7/8”(860) 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) 39 3/4”(1010) 38”(965) 37 1/2”(953) 33 7/8”(860) 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) PQR3636 PQR3838 49 3/4”(1264) 48”(1219) 47 1/2”(1207) 43
Fixed, Radius and Geometric Windows Premium Vinyl QUARTER ROUND 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 55 3/4”(1416) 54”(1372) 53 1/2”(1359) 49 7/8”(1267) 55 3/4”(1416) 54”(1372) 53 1/2”(1359) 49 7/8”(1267) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING PQR5454 PQR6060 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING PQR66
Fixed, Radius and Geometric Windows Premium Vinyl HALF ROUND 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) PHR3819 18 3/4”(476) 17”(432) 16 1/2”(419) 12 7/8”(327) 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) PHR5427 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) 34 3/4”(883) 33”(838) 32 1/2”(826) 28 7/8”(733) 33 3/4”(857) 32”(813) 31 1/2”(800) 27 7/8”(708) 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) PHR6030 69 3/4”(1772) 68”(1727) 67 1/2”(1715) 63 7/8”(1622) 35 3/4”(908) 34”(864
Fixed, Radius and Geometric Windows Premium Vinyl FULL ROUND PFR30 PFR34 39 3/4”(1010) 38”(965) 37 1/2”(953) 33 7/8”(860) 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) PFR38 PFR42 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 55 3/4”(1416) 54”(1372) 53 1/2”(1359) 49 7/8”(1267) PFR48 PFR54 PFR60 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) 73 3/4”(1873) 72”(1829) 71 1/2”(181
Fixed, Radius and Geometric Windows Premium Vinyl QUARTER CIRCLE SEGMENT PQE5448 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) PQE4842 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) PQE6054 PQE6660 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING PQE4236 55 3/4”(1416) 54”(1372) 53 1/2”(1359) 49 7/8”(1267) 55 3/4”(1416) 54”(1372)
Fixed, Radius and Geometric Windows Premium Vinyl CIRCLE SEGMENT UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 19 3/4”(502) 18”(457) 17 1/2”(445) 13 7/8”(352) 13 3/4”(349) 12”(305) 11 1/2”(292) 7 7/8”(200) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) PEY3012 PEY3612 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) 49 3/4”(1264) 48”(1219) 47 1/2”(1207) 43 7/8”(1114) PEY4218 PEY4818 55 3/4”(1416) 54”(1372) 53 1/2”(1359) 49 7/8”(1267)
Fixed, Radius and Geometric Windows Premium Vinyl EXTENDED QUARTER ROUND 19 3/4”(502) 18”(457) 17 1/2”(445) 13 7/8”(352) 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) PQT1848 PQT2448 PQT3048 PQT3648 PQT1854 PQT2454 PQT3054 PQT3654 PQT1860 PQT2460 PQT3060 PQT3660 PQT1866 PQT2466 PQT3066 PQT3666 PQT1872 PQT2472 PQT3072 PQT3672 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) 67 3/4”(17
Fixed, Radius and Geometric Windows Premium Vinyl EXTENDED HALF ROUND 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) 49 3/4”(1264) 48”(1219) 47 1/2”(1207) 43 7/8”(1114) PSL2436 PSL3036 PSL3636 PSL4236 PSL4836 PSL2442 PSL3042 PSL3642 PSL4242 PSL4842 PSL2448 PSL3048 PSL3648 PSL4248 PSL4848 PSL2454 PSL3054 PSL3654 PSL4254 PSL4854 PSL2460 P
Fixed, Radius and Geometric Windows Premium Vinyl EXTENDED HALF ROUND 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) 49 3/4”(1264) 48”(1219) 47 1/2”(1207) 43 7/8”(1114) PSL2472 PSL3072 PSL3672 PSL4272 PSL4872 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING ELEVATION SYMBOL LEGEND: VALUES IN ()
Fixed, Radius and Geometric Windows Premium Vinyl EXTENDED QUARTER SEGMENT 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) 49 3/4”(1264) 48”(1219) 47 1/2”(1207) 43 7/8”(1114) 55 3/4”(1416) 54”(1372) 53 1/2”(1359) 49 7/8”(1267) PQP2424 PQP3024 PQP3624 PQP4224 PQP4824 PQP5424 PQP2430 PQP3030 PQP3630 PQP4230 PQP4830 PQP5430 PQP2436 PQP3036 PQP363
Fixed, Radius and Geometric Windows Premium Vinyl EXTENDED QUARTER SEGMENT 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) 49 3/4”(1264) 48”(1219) 47 1/2”(1207) 43 7/8”(1114) 55 3/4”(1416) 54”(1372) 53 1/2”(1359) 49 7/8”(1267) PQP2466 PQP3066 PQP3666 PQP4266 PQP4866 PQP5466 PQP2472 PQP3072 PQP3672 PQP4272 PQP4872 PQP5472 73 3/4”(1873) 72”(1829)
Fixed, Radius and Geometric Windows Premium Vinyl EXTENDED QUARTER SEGMENT 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING PQP6624 PQP7224 PQP6030 PQP6630 PQP7230 PQP6036 PQP6636 PQP7236 PQP6042 PQP6642 PQP7242 PQP6048 PQP6648 PQP7248 PQP6054 PQP6654 PQP7254 PQP6060 PQP6660 PQP72
Fixed, Radius and Geometric Windows Premium Vinyl EXTENDED QUARTER SEGMENT 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING PQP6666 PQP7266 PQP6072 PQP6672 PQP7272 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) PQP6066 ELEVATION SYMBOL LEGEND: VALUES IN () ARE IN MILLIMETER CONVERSIO
Fixed, Radius and Geometric Windows Premium Vinyl EXTENDED CIRCLE SEGMENT 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) 49 3/4”(1264) 48”(1219) 47 1/2”(1207) 43 7/8”(1114) 55 3/4”(1416) 54”(1372) 53 1/2”(1359) 49 7/8”(1267) 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING PLP3024 PLP3624 PLP4224 PLP4
Fixed, Radius and Geometric Windows Premium Vinyl EXTENDED CIRCLE SEGMENT 25 3/4”(654) 24”(610) 23 1/2”(597) 19 7/8”(505) 31 3/4”(806) 30”(762) 29 1/2”(749) 25 7/8”(657) 37 3/4”(959) 36”(914) 35 1/2”(902) 31 7/8”(810) 43 3/4”(1111) 42”(1067) 41 1/2”(1054) 37 7/8”(962) 49 3/4”(1264) 48”(1219) 47 1/2”(1207) 43 7/8”(1114) 55 3/4”(1416) 54”(1372) 53 1/2”(1359) 49 7/8”(1267) PLP2466 PLP3066 PLP3666 PLP4266 PLP4866 PLP5466 PLP2472 PLP3072 PLP3672 PLP4272 PLP4872 PLP5472 73 3/4”(1873) 72”(1829)
Fixed, Radius and Geometric Windows Premium Vinyl EXTENDED CIRCLE SEGMENT 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) PLP6024 PLP6624 PLP7224 PLP6030 PLP6630 PLP7230 PLP6036 PLP6636 PLP7236 PLP6042 PLP6642 PLP7242 PLP6048 PLP6648 PLP7248 PLP6054 PLP6654 PLP7254 PLP6060 PLP6660 PLP7260 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 55 3/4”(1416) 54”(1372) 53 1/2”(1359)
Fixed, Radius and Geometric Windows Premium Vinyl EXTENDED CIRCLE SEGMENT 61 3/4”(1568) 60”(1524) 59 1/2”(1511) 55 7/8”(1419) 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) PLP6066 PLP6666 PLP7266 PLP6072 PLP6672 PLP7272 73 3/4”(1873) 72”(1829) 71 1/2”(1816) 67 7/8”(1724) 67 3/4”(1721) 66”(1676) 65 1/2”(1664) 61 7/8”(1572) UNIT SIZE ROUGH OPENING FRAME SIZE DAYLIGHT OPENING ELEVATION SYMBOL LEGEND: VALUES IN () ARE IN MILLIMETER CONVERSION
Fixed, Radius and Geometric Windows Premium Vinyl SASH GLAZING OPTIONS: 4” SCALE 5/8” FLAT GBG BAR 1” CONTOUR GBG BAR 5/16” 3/16” 5/8” 7/8” SDL BAR 1” 1 1/8” SDL BAR 1 3/8” SDL BAR 2 1/8” SDL BAR 3/16” 3/16” 3/16” 3/16” 1 1/8” 7/8” 1 11/16” 1 11/16” 2 13/16” 2 13/16” 1/4” GLASS 1 11/16” 2 13/16” 1 11/16” 2 13/16” 3/16” GLASS 1 11/16” Architectural Detail Manual July 2010 1 11/16” 2 13/16” STANDARD GLASS 2 13/16” 2 1/8” 1 3/8” 1 11/16” 2 13/16” JELD-WEN reserves the right to ch
Fixed, Radius and Geometric Windows Premium Vinyl GRILLE & SDL LITE PATTERNS PICTURE STANDARD PRAIRIE COLONIAL TOP 1/2 FULL ROUND FR4 Architectural Detail Manual July 2010 FR4 JELD-WEN reserves the right to change specifications without notice.
Fixed, Radius and Geometric Windows Premium Vinyl GRILLE & SDL LITE PATTERNS QUARTER ROUND QR2 QR7 QR11 QR15 QR20 Architectural Detail Manual July 2010 QR3 QR5 QR6 QR8 QR9 QR10 QR12 QR16 QR21 QR13 QR14 QR19 QR22 JELD-WEN reserves the right to change specifications without notice.
Fixed, Radius and Geometric Windows Premium Vinyl GRILLE & SDL LITE PATTERNS HALF ROUND HR-3 HR-5 HR-6 HR-7 HR-8 HR-9 HR-10 HR-11 HR-12 HR-13 HR-14 HR-15 HR-16 HR-17 HR-18 HR-19 HR-20 HR-23 HR-24 Architectural Detail Manual July 2010 JELD-WEN reserves the right to change specifications without notice.
Fixed, Radius and Geometric Windows Premium Vinyl GRILLE & SDL LITE PATTERNS EXTENDED QUARTER ROUND QT1 QT2 EXTENDED HALF ROUND RT1 RT3 RT2 RT4 EXTENDED CIRCLE SEGMENT LP1 LP2 LP3 LP4 LP5 LP7 LP8 LP14 LP16 LP18 Architectural Detail Manual July 2010 JELD-WEN reserves the right to change specifications without notice.
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE WINDOW NAILING FIN 3 1/4” 1 1/4” 1 15/16” 5/8” 5/8” 1/2” 2 7/16” Frame Size Rough Opening Daylight Opening Unit Size Glass Size 1/2” 1/2” 2 7/16” 5/8” 1 1/4” 5/8” 1 15/16” 3 1/4” VERTICAL SECTION SCALE: 4” = 1’ Architectural Detail Manual July 2010 JELD-WEN reserves the right to change specifications without notice.
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE WINDOW NAILING FIN Rough Opening 1/4” 1/4” Frame Size 5/8” 5/8” 1 15/16” 1 15/16” 3 1/4” 3 1/4” 1 1/4” 1 1/4” 5/8” 5/8” 1/2” 1/2” Daylight Opening 2 7/16” Glass Size 2 7/16” Unit Size HORIZONTAL SECTION SCALE: 4” = 1’ Architectural Detail Manual July 2010 JELD-WEN reserves the right to change specifications without notice.
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE WINDOWS FLUSH FIN 3 3/8” 7/16” 3” 2 15/16” 5/8” 1/2” Frame Size Rough Opening Daylight Opening Unit Size Glass Size 1/2” 1/2” 2 15/16” 5/8” 3” 7/16” 3 3/8” VERTICAL SECTION SCALE: 4” = 1’ Architectural Detail Manual July 2010 JELD-WEN reserves the right to change specifications without notice.
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE WINDOW FLUSH FIN Rough Opening 1/4” 1/4” Frame Size 5/8” 5/8” 3 3/8” 3” 3” 7/16” 3 3/8” 7/16” 1/2” 1/2” Daylight Opening 2 15/16” Glass Size 2 15/16” Unit Size HORIZONTAL SECTION SCALE: 4” = 1’ Architectural Detail Manual July 2010 JELD-WEN reserves the right to change specifications without notice.
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE WINDOWS BOX FRAME 3 1/4” 5/8” 5/8” 1/2” 1 5/16” Frame Size Rough Opening Daylight Opening Unit Size Glass Size 1/2” 1/2” 1 5/16” 5/8” 5/8” 3 1/4” VERTICAL SECTION SCALE: 4” = 1’ Architectural Detail Manual July 2010 JELD-WEN reserves the right to change specifications without notice.
Fixed, Radius and Geometric Windows Premium Vinyl PICTURE WINDOWS BOX FRAME Rough Opening 1/4” Frame Size 1/4” 5/8” 5/8” 3 1/4” 3 1/4” 5/8” 5/8” 1/2” 1/2” Daylight Opening 1 5/16” Glass Size 1 5/16” Unit Size HORIZONTAL SECTION SCALE: 4” = 1’ Architectural Detail Manual July 2010 JELD-WEN reserves the right to change specifications without notice.
