Dimensions Guide

Architectural Detail Manual
July 2010
JELD-WEN reserves the right to change specifications without notice.
Pa
g
e7-25
EXTENDED HALF ROUND
72”(1829)
73 3/4”(1873) 71 1/2”(1816) 67 7/8”(1724)
PSL2472
PSL3072 PSL3672
PSL4272 PSL4872
DAYLIGHT OPENING
FRAME SIZE
ROUGH OPENING
UNIT SIZE
24”(610)
25 3/4”(654)
23 1/2”(597)
19 7/8”(505)
30”(762)
31 3/4”(806)
29 1/2”(749)
25 7/8”(657)
36”(914)
37 3/4”(959)
35 1/2”(902)
31 7/8”(810)
42”(1067)
43 3/4”(1111)
41 1/2”(1054)
37 7/8”(962)
48”(1219)
49 3/4”(1264)
47 1/2”(1207)
43 7/8”(1114)
ELEVATION SYMBOL LEGEND:
VALUES IN () ARE IN MILLIMETER CONVERSIONS
## INDICAT ES DESIGN PRESSURE (DP) RATING WITH STANDARD GLAZING
Note: Elevations shown DO NOT have exterior trim. Subtract 1/2”(12.7) from M.O.(Masonry Opening) for Unit Sizes. Masonry openings above include SillNose,seeTrimOptions
page for Si ll Nose specifications. For other Trim Options refer to the Unit Sizing, Rough Opening & Masonry Openings page.
Fixed, Radius and Geometric Windows
Premium Vinyl
SCALE: 1
/
4” = 1’
