Dimensions Guide

Architectural Detail Manual
July 2010
JELD-WEN reserves the right to change specifications without notice.
Pa
g
e7-15
PICTURE UNITS
PPC7890
35
DAYLIGHT OPENING
FRAME SIZE
ROUGH OPENING
UNIT SIZE
90”(2286)
91 3/4”(2330) 89 1/2”(2273) 85 7/8”(2181)
78”(1981)
79 3/4”(2026)
77 1/2”(1969)
73 7/8”(1876)
ELEVATION SYMBOL LEGEND:
VALUES IN () ARE IN MILLIMETER CONVERSIONS
## INDICAT ES DESIGN PRESSURE (DP) RATING WITH STANDARD GLAZING
Note: Elevations shown DO NOT have exterior trim. Subtract 1/2”(12.7) from M.O.(Masonry Opening) for Unit Sizes. Masonry openings above include SillNose,seeTrimOptions
page for Si ll Nose specifications. For other Trim Options refer to the Unit Sizing, Rough Opening & Masonry Openings page.
Fixed, Radius and Geometric Windows
Premium Vinyl
SCALE: 1
/
4” = 1’
