PRODUCT SPECIFICATIONS
MATERIALS
Extruded vinyl profiles comply with the performance requirements of
AAMA 303-97. Colors are White and Desert S and. Available in the
West.
FRAME
All frames are assembled utilizing fusion-welded technology for
added strength and durability . Frame jamb depth is 3-1/4“
(82.55mm), and the exterior wall thickness is 0.070 of an inch. Frames
come standardwithintegral nailing fin that can be easily removedfor
replacement purposes. An optional integral dual-wall Flush Fin is
available for some retrofit applications. Dual-wall Flush Fin is not
available on radius and some geometric configurations.
GLAZING
3/4” (19mm) insulating glass consists of two lites of glass sealed
around a spacer. All insulating glass units comply with the
performance requirements of the IGCC in accordance with either
ASTM E774 or E2190.
GLAZING OPTIONS
3/4” (19mm) insulated glass available in clear, Low-E, tinted, obscure,
or other specialty insulating glass as specified. All glass is available
tempered.
GRILLES
SDL (Simulated Divided Lite) - 7/8“ (23mm), 1-1/8“ (29mm), 1-3/8“
(35mm), or 2-1/8” (58mm) contour grilles surface mounted on the
exterior surfaces of the insulating glass, with shadow bars mounted
between the glass panes suspended within the air cavity.
GBG (Grilles between the Glass) - 5/8” (16mm) flat or 1” (26mm)
contour grilles mounted between the glass panes suspended within
the air cavity and color matched to the extrusion color.
INSTALLATION
Installation per JELD-WEN Installation Method for Vinyl Windows
JII001, JII010 or JII011. See www.jeld-wen.com/resources for
instructions.
PERFORMANCE
NFRC Certified -(ratedandlabeledinaccordancewithNFRC)
AAMA/NWDMA I.S.2-97
R20-DP rated standard
Optional C35-DP rated (optional glazing required)
Fixed, Radius and Geometric Windows
Premium Vinyl
