Dimensions Guide

Architectural Detail Manual
July 2010
JELD-WEN reserves the right to change specifications without notice.
Pa
g
e7-24
EXTENDED HALF ROUND
DAYLIGHT OPENING
FRAME SIZE
ROUGH OPENING
UNIT SIZE
PSL2436 PSL3036 PSL3636 PSL4236 PSL4836
24”(610)
25 3/4”(654)
23 1/2”(597)
19 7/8”(505)
30”(762)
31 3/4”(806)
29 1/2”(749)
25 7/8”(657)
36”(914)
37 3/4”(959)
35 1/2”(902)
31 7/8”(810)
42”(1067)
43 3/4”(1111)
41 1/2”(1054)
37 7/8”(962)
48”(1219)
49 3/4”(1264)
47 1/2”(1207)
43 7/8”(1114)
36”(914)
37 3/4”(959) 35 1/2”(902) 31 7/8”(810)
42”(1067)
43 3/4”(1111) 41 1/2”(1054)
37 7/8”(962)
48”(1219)
49 3/4”(1264) 47 1/2”(1207) 43 7/8”(1114)
54”(1372)
55 3/4”(1416) 53 1/2”(1359) 49 7/8”(1267)
60”(1524)
61 3/4”(1568) 59 1/2”(1511) 55 7/8”(1419)
66”(1676)
67 3/4”(1721) 65 1/2”(1664) 61 7/8”(1572)
PSL2442 PSL3042 PSL3642 PSL4242 PSL4842
PSL2448 PSL3048 PSL3648 PSL4248 PSL4848
PSL2454 PSL3054 PSL3654 PSL4254 PSL4854
PSL2460 PSL3060 PSL3660 PSL4260 PSL4860
PSL2466 PSL3066 PSL3666 PSL4266 PSL4866
ELEVATION SYMBOL LEGEND:
VALUES IN () ARE IN MILLIMETER CONVERSIONS
## INDICAT ES DESIGN PRESSURE (DP) RATING WITH STANDARD GLAZING
Note: Elevations shown DO NOT have exterior trim. Subtract 1/2”(12.7) from M.O.(Masonry Opening) for Unit Sizes. Masonry openings above include SillNose,seeTrimOptions
page for Si ll Nose specifications. For other Trim Options refer to the Unit Sizing, Rough Opening & Masonry Openings page.
Fixed, Radius and Geometric Windows
Premium Vinyl
SCALE: 1
/
4” = 1’
