Dimensions Guide

Architectural Detail Manual
July 2010
JELD-WEN reserves the right to change specifications without notice.
Pa
g
e7-34
5/8” FLAT GBG BAR 1” CONTOUR GBG BAR
7/8” SDL BAR
11/8”SDLBAR 13/8”SDLBAR 21/8”SDLBAR
1”
5/8”
3/16”
5/16”
7/8”
11/8”
13/8”
21/8”
3/16”
3/16”
3/16”
3/16”
STANDARD GLASS 3/16” GLASS 1/4” GLASS
213/16”
111/16”
213/16”
111/16”
213/16”
111/16”
213/16”
111/16”
213/16”
111/16”
213/16”
111/16”
213/16”
111/16”
SASH GLAZING OPTIONS: 4” SCALE
Fixed, Radius and Geometric Windows
Premium Vinyl
