Dimensions Guide

Architectural Detail Manual
July 2010
JELD-WEN reserves the right to change specifications without notice.
Pa
g
e7-6
PICTURE UNITS
PPC1290 PPC1890 PPC2290 PPC2490 PPC2690 PPC3090 PPC3290 PPC3490
PPC1296 PPC1896 PPC2296 PPC2496 PPC2696 PPC3096 PPC3296 PPC3496
90”(2286)
91 3/4”(2330) 89 1/2”(2273) 85 7/8”(2181)
96”(2438)
97 3/4”(2483) 95 1/2”(2426) 91 7/8”(2334)
35 35 35 35 35 35 35 35
35 35 35 35 35 35 35 35
12”(305)
13 3/4”(349)
11 1/2”(292)
77/8”(200)DAYLIGHT OPENING
FRAME SIZE
ROUGH OPENING
UNIT SIZE
18”(457)
19 3/4”(502)
17 1/2”(445)
13 7/8”(352)
22”(559)
23 3/4”(603)
21 1/2”(546)
17 7/8”(454)
24”(610)
25 3/4”(654)
23 1/2”(597)
19 7/8”(505)
26”(660)
27 3/4”(705)
25 1/2”(648)
21 7/8”(556)
30”(762)
31 3/4”(806)
29 1/2”(749)
25 7/8”(657)
32”(813)
33 3/4”(857)
31 1/2”(800)
27 7/8”(708)
34”(864)
35 3/4”(908)
33 1/2”(851)
29 7/8”(759)
ELEVATION SYMBOL LEGEND:
VALUES IN () ARE IN MILLIMETER CONVERSIONS
## INDICAT ES DESIGN PRESSURE (DP) RATING WITH STANDARD GLAZING
Note: Elevations shown DO NOT have exterior trim. Subtract 1/2”(12.7) from M.O.(Masonry Opening) for Unit Sizes. Masonry openings above include SillNose,seeTrimOptions
page for Si ll Nose specifications. For other Trim Options refer to the Unit Sizing, Rough Opening & Masonry Openings page.
Fixed, Radius and Geometric Windows
Premium Vinyl
SCALE: 1
/
4” = 1’
