Dimensions Guide

Architectural Detail Manual
July 2010
JELD-WEN reserves the right to change specifications without notice.
Pa
g
e7-7
PICTURE UNITS
PPC3612 PPC3812 PPC4212 PPC4812 PPC5412
PPC3618 PPC3818 PPC4218 PPC4818 PPC5418
PPC3624 PPC3824 PPC4224 PPC4824 PPC5424
PPC3630 PPC3830 PPC4230 PPC4830 PPC5430
PPC3636 PPC3836 PPC4236 PPC4836 PPC5436
PPC3642 PPC3842 PPC4242 PPC4842 PPC5442
PPC3648 PPC3848 PPC4248 PPC4848 PPC5448
PPC3654 PPC3854 PPC4254 PPC4854 PPC5454
36”(914)
37 3/4”(959)
35 1/2”(902)
31 7/8”(810)
38”(965)
39 3/4”(1010)
37 1/2”(953)
33 7/8”(860)
42”(1067)
43 3/4”(1111)
41 1/2”(1054)
37 7/8”(962)
48”(1219)
49 3/4”(1264)
47 1/2”(1207)
43 7/8”(1114)
54”(1372)
55 3/4”(1416)
53 1/2”(1359)
49 7/8”(1267)
35 35 35 35 35
35 35 35 35 35
35 35 35 35 35
35 35 35 35 35
35 35 35 35 35
35 35 35 35 35
35 35 35 35 35
35 35 35 35 35
DAYLIGHT OPENING
FRAME SIZE
ROUGH OPENING
UNIT SIZE
12”(305)
13 3/4”(349) 11 1/2”(292)
77/8”(200)
18”(457)
19 3/4”(502) 17 1/2”(445) 13 7/8”(352)
24”(610)
25 3/4”(654) 23 1/2”(597)
19 7/8”(505)
30”(762)
31 3/4”(806) 29 1/2”(749) 25 7/8”(657)
36”(914)
37 3/4”(959) 35 1/2”(902) 31 7/8”(810)
42”(1067)
43 3/4”(1111) 41 1/2”(1054)
37 7/8”(962)
48”(1219)
49 3/4”(1264) 47 1/2”(1207) 43 7/8”(1114)
54”(1372)
55 3/4”(1416) 53 1/2”(1359) 49 7/8”(1267)
ELEVATION SYMBOL LEGEND:
VALUES IN () ARE IN MILLIMETER CONVERSIONS
## INDICAT ES DESIGN PRESSURE (DP) RATING WITH STANDARD GLAZING
Note: Elevations shown DO NOT have exterior trim. Subtract 1/2”(12.7) from M.O.(Masonry Opening) for Unit Sizes. Masonry openings above include SillNose,seeTrimOptions
page for Si ll Nose specifications. For other Trim Options refer to the Unit Sizing, Rough Opening & Masonry Openings page.
Fixed, Radius and Geometric Windows
Premium Vinyl
SCALE: 1
/
4” = 1’
