Dimensions Guide

Architectural Detail Manual
July 2010
JELD-WEN reserves the right to change specifications without notice.
Pa
g
e7-11
PICTURE UNITS
PPC6060 PPC6660 PPC7260
PPC6066 PPC6666 PPC7266
PPC6072 PPC6672 PPC7272
PPC6078 PPC6678 PPC7278
PPC6084 PPC6684 PPC7284
35 35 35
35 35 35
35 35 35
35 35 35
35 35 35
60”(1524)
61 3/4”(1568)
59 1/2”(1511)
55 7/8”(1419)
66”(1676)
67 3/4”(1721)
65 1/2”(1664)
61 7/8”(1572)
72”(1829)
73 3/4”(1873)
71 1/2”(1816)
67 7/8”(1724)DAYLIGHT OPENING
FRAME SIZE
ROUGH OPENING
UNIT SIZE
60”(1524)
61 3/4”(1568) 59 1/2”(1511) 55 7/8”(1419)
66”(1676)
67 3/4”(1721) 65 1/2”(1664) 61 7/8”(1572)
72”(1829)
73 3/4”(1873) 71 1/2”(1816) 67 7/8”(1724)
78”(1981)
79 3/4”(2026) 77 1/2”(1969) 73 7/8”(1876)
84”(2134)
85 3/4”(2178) 83 1/2”(2121) 79 7/8”(2029)
Fixed, Radius and Geometric Windows
Premium Vinyl
SCALE: 1
/
4” = 1’
