Dimensions Guide

Architectural Detail Manual
July 2010
JELD-WEN reserves the right to change specifications without notice.
Pa
g
e7-30
EXTENDED CIRCLE SEGMENT
DAYLIGHT OPENING
FRAME SIZE
ROUGH OPENING
UNIT SIZE
PLP2424
PLP3024 PLP3624
PLP4224
PLP4824 PLP5424
24”(610)
25 3/4”(654)
23 1/2”(597)
19 7/8”(505)
30”(762)
31 3/4”(806)
29 1/2”(749)
25 7/8”(657)
36”(914)
37 3/4”(959)
35 1/2”(902)
31 7/8”(810)
42”(1067)
43 3/4”(1111)
41 1/2”(1054)
37 7/8”(962)
48”(1219)
49 3/4”(1264)
47 1/2”(1207)
43 7/8”(1114)
54”(1372)
55 3/4”(1416)
53 1/2”(1359)
49 7/8”(1267)
24”(610)
25 3/4”(654) 23 1/2”(597)
19 7/8”(505)
30”(762)
31 3/4”(806) 29 1/2”(749) 25 7/8”(657)
36”(914)
37 3/4”(959) 35 1/2”(902) 31 7/8”(810)
42”(1067)
43 3/4”(1111) 41 1/2”(1054)
37 7/8”(962)
48”(1219)
49 3/4”(1264) 47 1/2”(1207) 43 7/8”(1114)
54”(1372)
55 3/4”(1416) 53 1/2”(1359) 49 7/8”(1267)
60”(1524)
61 3/4”(1568) 59 1/2”(1511) 55 7/8”(1419)
PLP2430 PLP3030 PLP3630 PLP4230 PLP4830 PLP5430
PLP2436 PLP3036 PLP3636 PLP4236 PLP4836 PLP5436
PLP2442 PLP3042 PLP3642 PLP4242 PLP4842 PLP5442
PLP2448 PLP3048 PLP3648 PLP4248 PLP4848 PLP5448
PLP2454 PLP3054 PLP3654 PLP4254 PLP4854 PLP5454
PLP2460 PLP3060 PLP3660 PLP4260 PLP4860 PLP5460
ELEVATION SYMBOL LEGEND:
VALUES IN () ARE IN MILLIMETER CONVERSIONS
## INDICAT ES DESIGN PRESSURE (DP) RATING WITH STANDARD GLAZING
Note: Elevations shown DO NOT have exterior trim. Subtract 1/2”(12.7) from M.O.(Masonry Opening) for Unit Sizes. Masonry openings above include SillNose,seeTrimOptions
page for Si ll Nose specifications. For other Trim Options refer to the Unit Sizing, Rough Opening & Masonry Openings page.
Fixed, Radius and Geometric Windows
Premium Vinyl
SCALE: 1
/
4” = 1’
